Solar Ramming C Column Foundation PV Ground Racking System
Solar C Post Pile Ground Mounting Bracket is applicable for both frame and frame-less modules, and widely used in small and large solar plants. The C shape galvanized steel pile used as structural dupport is designed to be quickly assembled under any field conditions. Compared with other solar ground mounting systems, this btacket has small footprint, strong compatibility and less penetrating resistance, but not affect the firmness, also saves time and cost on installation site.
Category: Ground mounting system
|
Name
|
C Type Pile Foundation Solar Ground Mounting System
|
|
Installation Site
|
Open Field Ground
|
|
Material
|
Hot dipped galvanized steel & Stainless steel & Aluminum
|
|
Wind Speed
|
<60M/S
|
|
Snow Load
|
<1.4KN/M2
|
|
Color
|
Natural
|
|
Warranty
|
10 years warranty and 25 years service time
|
Advantages as follow:
☆ Widely application--can work under any ground and soil conditions.
☆ Adjustable solar angle 0-60 degree - Win more solar energy during solar tilt angle change.
☆ High pre-assembly--save time and labor cost, require less tools.
☆ C-type pile has strong load bearing, high corrosion resistance, salt tolerance.
☆ Fast installation--use piledriver ramming C-type piles directly into the earth.
Related certificate:
Strength Analysis report -- mountings will be test to meet your target strength, Like wind speed and snow load.
Our standard package is steel pallet for long alu profile, while small alu components will be packed into cartons with plywood pallet.
