Technical
Specifications
|
|
|
Slot Provided
|
|
|
Type
|
Expansion
slot
|
|
Total Qty
|
1
|
|
Free Qty
|
1
|
|
Interface
Provided
|
|
|
Qty
|
48
|
|
Type
|
1000Base-T
|
|
Comments
|
PoE+
|
|
Connector Type
|
RJ-45
|
|
Networking
|
|
|
Type
|
Switch
|
|
Remote Management Protocol
|
CLI,
NETCONF, RESTCONF, RMON 1, RMON 2, SNMP, SNMP 1, SNMP 2c, SNMP 3
|
|
Compliant Standards
|
IEEE
802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE
802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE
802.3u, IEEE 802.3x
|
|
Status Indicators
|
Status
|
|
Ports Qty
|
24
|
|
Features
|
16MB
packet buffer, 3 fans, 802.1x authentication, Access Control List (ACL)
support, Application Visibility and Control (AVC), Cisco StackPower
technology, Cisco StackWise-480 technology, Class-Based Weighted Fair Queuing
(CBWFQ), Control plane protection (CoPP), DHCP support, Encapsulated Remote
SPAN (ERSPAN), Ethernet over MPLS (EoMPLS), Flexible NetFlow (FNF), FTP
client, Full duplex mode, Hierarchical Virtual Private LAN Service (H-VPLS),
Integrated Wireshark, IT Service Management (ITSM) integration, Layer 3 VPN
(L3VPN) support, MACsec support, Management Information Base (MIB), Multicast
Source Discovery Protocol (MSDP), Non-Stop Routing (NSR), Private VLAN,
Quality of Service (QoS), Remote Switch Port Analyzer (RSPAN), Security Group
Access Control List (SGACL), Security Group Tag (SGT) caching,
Source-Specific Multicast (SSM), Spanning Tree Protocol (STP) support,
Stateful switchover (SSO), Syslog support, Third-party IP Address Management
(IPAM) integration, Trunking, Virtual Extensible LAN (VXLAN), VLAN Double
Tagging (Q-in-Q), Weighted Random Early Detection (WRED)
|
|
Routing Protocol
|
BGP,
EIGRP, HSRP, IGMP, IS-IS, MSDP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based
routing (PBR), RIP-1, RIP-2, RIPng, VRRP
|
|
MAC Address Table Size
|
32000
entries
|
|
Stackable
|
Stackable
|
|
Subcategory
|
Network
hubs and switches
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
Advanced Switching
|
Layer
3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Rack-mountable
|
|
Jumbo Frame Support
|
9198
bytes
|
|
Subtype
|
Gigabit
Ethernet
|
|
PoE Budget
|
445
W
|
|
Miscellaneous
|
|
|
Compliant Standards
|
AS/NZS
3548 Class A, BSMI Class A, CAN/CSA C22.2 No. 60950-1, CCC, CISPR 22 Class A,
CISPR 24, EN 300386, EN 55022 Class A, EN 60950-1, EN 61000-3-2, EN
61000-3-3, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6, EN 61000-6-1, EN50082-1, EN55024, FCC CFR47 Part 15 A, ICES-003
Class A, IEC 60950-1, RoHS 5/6, TVCN 7317, UL 60950-1, VCCI Class A, VCCI
V-3/2009 Class A
|
|
MTBF
|
299,000
hours
|
|
Height (Rack Units)
|
1
|
|
Encryption Algorithm
|
128-bit
AES
|
|
Color Category
|
Gray
|
|
Environmental
Parameters
|
|
|
Min Operating Temperature
|
23
°F
|
|
Max Operating Temperature
|
113
°F
|
|
Humidity Range Operating
|
5
- 90% (non-condensing)
|
|
Min Storage Temperature
|
158
°F
|
|
Max Storage Temperature
|
104
°F
|
|
Humidity Range Storage
|
5
- 90% (non-condensing)
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco
Systems
|
|
Packaged Quantity
|
1
|
|
Product Line
|
Cisco
Catalyst
|
|
Model
|
9300
|
|
Brand
|
Cisco
|
|
Edition
|
Network
Advantage
|
|
Power Device
|
|
|
Frequency Required
|
50
- 60 Hz
|
|
Power Provided
|
715
Watt
|
|
Installed Qty
|
1
|
|
Max Supported Qty
|
2
|
|
Nominal Voltage
|
AC
120/230 V
|
|
Power Redundancy
|
Optional
|
|
Type
|
Internal
power supply
|
|
Hot-Plug
|
Hot-plug
|
|
Service
|
|
|
Support Details Type
|
Technical
support
|
|
Support Details Service Included
|
Consulting
|
|
Support Details Full Contract Period
|
90
days
|
|
Software
|
|
|
Type
|
25
x Cisco ONE ISE BASE Licenses Term, 25 x Cisco ONE ISE PLUS Licenses Term,
Cisco ONE C9300 Advantage Add-On Term, Cisco ONE C9300 DNA Advantage 48-port
Term license, Cisco ONE StealthWatch License Term - 25 Flow Licenses
|
|
System
Requirements
|
|
|
Min Operating System
|
Cisco
IOS Universal
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5
in
|
|
Depth
|
17.5
in
|
|
Height
|
1.7
in
|
|
Weight
|
16.31
lbs
|
|
Service &
Support
|
|
|
Type
|
Limited
lifetime warranty
|
|
Capacity
|
|
|
Type
|
VLAN
IDs
|
|
Value
|
4000
|
|
Flash Memory
|
|
|
Installed Size
|
16
GB
|
|
Performance
|
|
|
Type
|
Switching
capacity
|
|
Value
|
128
Gbps
|
|
Ports
|
|
|
Qty
|
24
|
|
Type
|
10/100/1000
(PoE+)
|
|
RAM
|
|
|
Installed Size
|
8
GB
|
|
|
