Description
CBTB carbon turbo blanket made from pure carbon fiber, and include a high temperature rated silica isnulation matting under the tight out layer for extra added protection againest extreme turbo-generated heat.
The inside layer material can be carbon fiber or special fiber. They are more durable than other turbo blankets or shields.
Feature
Interior Surface:
Max Temperature Rating: 2300 Deg F/ 1260 Deg C
Continuous Use Limit: 1832 Deg F/ 1000 Deg C
Exterior Surface:
Direct Contact Limit: 1800 Deg F/ 982 Deg C
Radiant Heat Limit: 2500 Deg F/ 1371 Deg C
Application
Turbo Heat Shield Blanket solve the problem of extreme underhood heat, stops heat damage of painted or carbon fiber hoods and helps turbos spool faster.
Specifications
|
Part number
|
size
|
|
CBTB-T1
|
T1
|
|
CBTB-T2
|
T2
|
|
CBTB-T25/T28
|
T25/T28
|
|
CBTB-T3
|
T3
|
|
CBTB-T3/T4
|
T3/T4
|
|
CBTB-T4
|
T4
|
|
CBTB-T6
|
T6
|
|
CBTB-SUBARU
|
Subaru WRX/STI
|
|
CBTB-HYUNDAI
|
Hyundai Genesis
|
|
CBTB-BMW
|
BMW 135i/335i/535i (N54 Engine)
|
|
CBTB-FIAT
|
FIAT 500 Abarth / 500T / 500L
|
|
CBTB-K04
|
K03/K04
|
|
CBTB-DODGE
|
Dodge Dart
|
Notes:
We have different style, we can make base on samples and drawing.
