advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
accurate & fast detection
|
|
high visitor flow rate usage
|
|
modular design, easy maintenance
|
|
high compatibility, high integration
|
All-around Pedestrian Safety Protection
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Over-force feedback control
When the gate is momentarily subjected to an impact force beyond the safe range, the gate can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.
Emergency open
The card-swiping automatic speed gate turnstile equips with emergency escape control device, to make the system automatically open the gate to evacuate pedestrian.
Triple anti-clamping
With triple anti-clamping technologies such as infrared anti-clamping, mechanical anti-clamping and anti-collision by advanced electric current detection, card-swiping automatic speed gate turnstile can protect pedestrian safety more comprehensively.
Advanced & Intelligent Turnstile Core Technology
Strong & stable mechanism structure
CMOLO's self-developed lossless modular mechanism structure and full CNC processing technology are to ensure that the precision, strength and concentricity of the mechanism. The transmission ratio is accurate, efficient and stable, and the rotation angle of the gate can be precisely controlled and the loss is reduced, so as to ensure the stability and long service life of the mechanism structure.
Long service life
The mechanism and control system of card-swiping automatic speed gate turnstile have been passed 10 million times life test.
Advanced core logic algorithm
Card-swiping automatic speed gate turnstile adopts advanced servo control system and DSP+ARM motor control technology, combined with the motor control algorithm independently developed by CMOLO, which can achieve precise control and positioning of the obstacle and maintain stable performance.
The automatic speed gate turnstile adopts CMOLO® patented passing detection algorithm and matrix photoelectric stereo detection technology, to sensitively detect illegal behaviors such as reversely passing and tailgating, and issues warnings in the form of sound and light, and can be linked with other security systems.
Customization
Direction Indicator
|
The installation position of direction indicator can be adjusted.
The shape of direction indicator can be customized.
|
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
|
| Lane width |
The maximum lane width of turnstile is 900mm, and the cabinet length can be increased accordingly |
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
