Caterpillar loader bearing 1M6573 1M-6573
|
P/N
|
1M-6573
|
Material:
|
GCR15
|
|
i/d
|
mm
|
O/D
|
mm
|
|
H
|
mm
|
Brand：
|
ZHZB
|
Precision
|
P0 , P6 , P5
|
Structure:
|
Tapered Roller Bearings
|
Product features:
1. Special bearing for loader
2. It has high radial and axial load capacity at the same time
3. High-strength bearing steel
4. The product has passed the real machine test
Our advantage:
100% factory quality inspection;
Allow small orders;
Effectively solve after-sales problems;
Better quality assurance;
There are many partners at home and abroad. trustworthy
Professional manufacturer of loader bearings. More than 15 years of manufacturing experience
Production Process
Product Photos
Any other parts for the slewing gearbox system you need , pls search from below picture and form list then mark to me , we will quote to you.
|
Pos.
|
Part No
|
Qty
|
Parts name
|
Comments
|
|
1.
|
8T-0336
|
[2]
|
FITTING-PRESSURE RELIEF
|
|
|
2.
|
9G-5317
|
[2]
|
SEAL GP-DUO-CONE
|
|
|
|
|
|
(EACH INCLUDES)
|
|
2A.
|
1M-9011
|
[2]
|
RING-TORIC
|
|
|
3.
|
9M-2744
|
[2]
|
CONE-BEARING (TAPERED ROLLER)
|
|
|
4.
|
130-8707 B
|
[1]
|
SHIM PACK (INCLUDES 15-SHIMS)
|
|
|
5.
|
133-4292
|
[1]
|
SEAL-LIP TYPE
|
|
|
6.
|
156-4773
|
[1]
|
RETAINER
|
|
|
7.
|
248-0833
|
[1]
|
PLUG AS-DRAIN
|
|
|
|
3S-9233
|
[1]
|
SEAL-O-RING
|
|
|
|
5L-4759
|
[1]
|
SEAL-O-RING
|
|
|
|
259-7138
|
[1]
|
PLUG
|
|
|
8.
|
299-5318
|
[2]
|
BEARING
|
|
|
9.
|
503-6316
|
[1]
|
HOUSING AS
|
|
|
|
095-0673 M
|
[3]
|
BOLT-SOCKET HEAD (M12X1.75X60-MM)
|
|
|
10.
|
362-8194
|
[1]
|
HOUSING-PINION
|
|
|
11.
|
370-1587
|
[1]
|
SHROUD AS
|
|
|
12.
|
503-6319
|
[2]
|
HOUSING-AXLE
|
|
|
13.
|
388-1398
|
[2]
|
NUT-BEARING
|
|
|
14.
|
458-8690
|
[1]
|
SUPPORT AS-TRUNNION
|
|
|
14A.
|
458-8691
|
[1]
|
BUSHING
|
|
|
15.
|
392-1782
|
[1]
|
SUPPORT AS-TRUNNION
|
|
|
15A.
|
213-1365
|
[1]
|
BUSHING
|
|
|
16.
|
434-4574
|
[2]
|
SHAFT-AXLE
|
|
|
17.
|
434-7982
|
[1]
|
TRUNNION
|
|
|
18.
|
164-4180
|
[2]
|
PLUG AS
|
|
|
|
|
|
(EACH INCLUDES)
|
|
|
7M-8485
|
[1]
|
SEAL-O-RING
|
|
|
|
9S-4181
|
[1]
|
PLUG (1-5/16-12-THD)
|
|
|
19.
|
1M-6573
|
[2]
|
CUP-BEARING (TAPERED ROLLER)
|
|
|
20.
|
242-1811 M
|
[26]
|
BOLT-CYLINDER HEAD (M16X2X220-MM)
|
|
|
21.
|
418-6609 M
|
[3]
|
BOLT-FLANGE HEAD (M8X1.25X80-MM)
|
|
|
22.
|
4B-9373
|
[2]
|
CONE-BEARING (TAPERED ROLLER)
|
|
|
23.
|
4B-9374
|
[2]
|
CUP-BEARING (TAPERED ROLLER)
|
|
|
24.
|
4F-7388
|
[2]
|
SEAL-O-RING
|
|
|
25.
|
4H-6520
|
[1]
|
SEAL-O-RING
|
|
|
26.
|
5P-8247
|
[64]
|
WASHER-HARD (17X32X3.5-MM THK)
|
|
|
27.
|
6C-5304 M
|
[26]
|
BOLT (M16X2X110-MM)
|
|
|
28.
|
6V-5686 M
|
[12]
|
BOLT (M16X2X50-MM)
|
|
|
29.
|
6V-7732 M
|
[6]
|
BOLT (M10X1.5X25-MM)
|
|
|
30.
|
7M-8485
|
[1]
|
SEAL-O-RING
|
|
|
31.
|
8F-1959
|
[2]
|
RING-RETAINING
|
|
|
32.
|
8T-0657 M
|
[10]
|
BOLT (M20X2.5X160-MM)
|
|
|
33.
|
8T-3282
|
[10]
|
WASHER-HARD (22X35X3.5-MM THK)
|
|
|
34.
|
9C-6041
|
[2]
|
DOWEL
|
|
|
35.
|
9X-2027
|
[6]
|
WASHER (11X18X2-MM THK)
|
|
|
36.
|
095-1691
|
[2]
|
SEAL-O-RING
|
|
|
37.
|
5M-6214
|
[1]
|
PLUG (1/8-27 PTF)
|
|
|
38.
|
1K-6853
|
[1]
|
FITTING-PRESSURE RELIEF
|
|
Company
ZHZB Mission:We are committed to providing bearing component solutions for all construction machinery and equipment!!!
ZHZB was established in 2004 and has been committed to the development and production of engineering machinery bearings. Our products are widely used in mining equipment, road machinery, metallurgy, wind power generation, excavators and other heavy equipment and have been well received by customers!
Packaging
Delivery：
1.We will send express delivery for less than 45 kg, which is more convenient door-to-door.
2.45-200 kg we will choose air transportation, the safest, fastest, and the most expensive
3.For more than 200 kg, we will send it by sea to reduce transportation costs.
Why choose us?
✬1.Trusted Product
✬2.Advanced Technology
✬3.Reliable Service
✬4.Competitive price
FAQ
Q1: I want to buy your products, how can I pay?
A: You can contact me through Whatsapp to send bank account to you.
Q2: If we don't find what we want on your website, what should we do?
A: You can email or Whatsapp us the descriptions and pictures of the products you need, we will check whether we have them. We develop new items every month. and some of them have not been uploaded to website in time. Or you can send us sample by express, we will develop this item for bulk purchasing.
Q3: Can we buy 1 pc of each item for quality testing?
A: Yes, we are glad to send lpc for quality testing if we have the item you need in stock
