Caterpillar Loader bearing 7K-8876 7K8876
|
P/N
|
7K-8876
|
Material:
|
GCR15
|
|
i/d
|
mm
|
O/D
|
mm
|
|
H
|
mm
|
Brand：
|
ZHZB
|
Precision
|
P0 , P6 , P5
|
Structure:
|
Tapered Roller Bearings
|
Product features:
1. Special bearing for loader
2. It has high radial and axial load capacity at the same time
3. High-strength bearing steel
4. The product has passed the real machine test
Our advantage:
100% factory quality inspection;
Allow small orders;
Effectively solve after-sales problems;
Better quality assurance;
There are many partners at home and abroad. trustworthy
Professional manufacturer of loader bearings. More than 15 years of manufacturing experience
Production Process
Product Photos
Any other parts for the system you need , pls search from below picture and form list then mark to me , we will quote to you.
|
Pos.
|
Part No
|
Qty
|
Parts name
|
Comments
|
|
1.
|
2K-2939
|
[2]
|
SEAL-O-RING
|
|
|
2.
|
8T-4223
|
[12]
|
WASHER-HARD (13.5X25.5X3-MM THK)
|
|
|
3.
|
5M-7142
|
[2]
|
SEAL-O-RING
|
|
|
4.
|
3W-5450
|
[2]
|
HOUSING
|
|
|
5.
|
111-9035
|
[2]
|
CONE-BEARING
|
|
|
6.
|
8T-5092 M
|
[12]
|
BOLT (M12X1.75X150-MM)
|
|
|
7.
|
8G-4392
|
[4]
|
SPRING-DISC
|
|
|
8.
|
8T-4187 M
|
[44]
|
BOLT (M20X2.5X80-MM)
|
|
|
9.
|
8T-4123
|
[44]
|
WASHER (22X35X3.5-MM THK)
|
|
|
10.
|
3W-5454
|
[2]
|
RING
|
|
|
11.
|
170-8714
|
[8]
|
DISC-FRICTION
|
|
|
12.
|
3W-5159
|
[6]
|
PLATE-PARKING BRAKE
|
|
|
13.
|
111-9033
|
[2]
|
CONE-BEARING
|
|
|
14.
|
111-9034
|
[2]
|
CUP-BEARING
|
|
|
15.
|
9W-6630
|
[2]
|
SEAL GP-DUO-CONE
|
|
|
|
|
|
(EACH INCLUDES)
|
|
|
4M-0736
|
[2]
|
RING-SEALING
|
|
|
16.
|
3W-5438
|
[2]
|
GEAR (10-TEETH)
|
|
|
17.
|
112-2365
|
[2]
|
SPINDLE
|
|
|
18.
|
117-8045
|
[2]
|
HUB
|
|
|
19.
|
6Y-3242 Y
|
[2]
|
SEGMENT GP-SPROCKET
|
|
|
20.
|
112-4959
|
[2]
|
GEAR-RING (60-TEETH)
|
|
|
21.
|
3W-5448
|
[2]
|
CARRIER AS
|
|
|
|
|
|
(EACH INCLUDES)
|
|
|
6V-3532 M
|
[6]
|
BOLT (M20X2.5X60-MM)
|
|
|
|
8T-3282
|
[6]
|
WASHER-HARD (22X35X3.5-MM THK)
|
|
|
22.
|
6V-2452
|
[6]
|
DOWEL
|
|
|
23.
|
6V-0440
|
[4]
|
PLUG
|
|
|
24.
|
2S-4078
|
[6]
|
SEAL-O-RING
|
|
|
25.
|
6V-0439
|
[2]
|
PLUG-MAGNETIC (BRAKE & DRIVE)
|
|
|
26.
|
112-4961
|
[2]
|
SHAFT
|
|
|
27.
|
3W-5447
|
[2]
|
COVER
|
|
|
28.
|
8T-4137 M
|
[12]
|
BOLT (M10X1.5X20-MM)
|
|
|
29.
|
8T-0357 M
|
[18]
|
BOLT (M16X2X70-MM)
|
|
|
30.
|
7K-8876
|
[12]
|
CUP-BEARING
|
|
|
31.
|
7K-8877
|
[12]
|
CONE-BEARING
|
|
|
32.
|
3W-5445
|
[6]
|
SHAFT
|
|
|
33.
|
112-4960
|
[6]
|
GEAR-PLANETARY (23-TEETH)
|
|
|
34.
|
7P-9571
|
[6]
|
PLUG
|
|
|
35.
|
7P-2429
|
[2]
|
PLATE-RETAINER
|
|
|
36.
|
9M-5892
|
[2]
|
SEAL-O-RING
|
|
|
37.
|
8T-4192 M
|
[12]
|
BOLT (M12X1.75X25-MM)
|
|
|
38.
|
6V-0327
|
[4]
|
CUP-BEARING (TAPERED ROLLER)
|
|
|
39.
|
6V-0328
|
[4]
|
CONE-BEARING (TAPERED ROLLER)
|
|
|
40.
|
8T-4140 M
|
[38]
|
BOLT (M16X2X60-MM)
|
|
|
41.
|
4S-5924
|
[2]
|
SEAL-O-RING
|
|
|
42.
|
112-2363
|
[1]
|
CASE AS (LH)
|
|
|
|
3W-5436
|
[1]
|
BUTTON-THRUST
|
|
|
43.
|
112-2364
|
[1]
|
CASE AS (RH)
|
|
|
|
3W-5436
|
[1]
|
BUTTON-THRUST
|
|
|
44.
|
113-2499
|
[2]
|
GEAR (59-TEETH)
|
|
|
45.
|
3S-9182
|
[2]
|
PLUG-MAGNETIC (BRAKE & DRIVE)
|
|
|
46.
|
5P-4920
|
[2]
|
RACE & ROLLER AS
|
|
|
47.
|
5P-4921
|
[2]
|
RACE-BEARING OUTER
|
|
|
48.
|
122-0404
|
[2]
|
PLATE
|
|
|
49.
|
6V-3263
|
[2]
|
SEAL-O-RING
|
|
|
50.
|
8G-1258
|
[2]
|
PLATE-PRESSURE
|
|
|
51.
|
6V-7981 M
|
[14]
|
BOLT (M10X1.5X70-MM)
|
|
|
52.
|
8G-1259
|
[2]
|
RING-LOCK
|
|
|
53.
|
113-2498
|
[2]
|
HOUSING
|
|
|
54.
|
4N-1230
|
[2]
|
SEAL-O-RING
|
|
|
55.
|
111-9036
|
[2]
|
CUP-BEARING
|
|
|
56.
|
3W-5451
|
[2]
|
PISTON
|
|
|
57.
|
8T-6379
|
[2]
|
SEAL AS
|
|
|
|
|
|
(EACH INCLUDES)
|
|
|
7J-8956
|
[1]
|
SEAL-O-RING (RUBBER)
|
|
|
|
8T-6378
|
[1]
|
SEAL-RING (PLASTIC)
|
|
|
58.
|
6V-6640 B
|
|
SEALANT
|
|
|
59.
|
6V-2455
|
[2]
|
SENSOR GP-SPEED (RPM)
|
|
|
|
|
|
(EACH INCLUDES)
|
|
|
102-8802
|
[1]
|
KIT-RECEPTACLE (2-PIN)
|
|
|
|
|
|
(INCLUDES RECEPTACLE AS & WEDGE)
|
|
|
8T-8729
|
[2]
|
PIN-CONNECTOR (16-GA TO 18-GA)
|
|
|
|
9X-1386 E
|
|
SLEEVE (14-CM)
|
|
|
60.
|
3W-5928
|
[2]
|
SEAL AS
|
|
|
61.
|
6H-3615
|
[2]
|
PLUG-PROTECTION
|
|
