Artificial Intelligence AI Ore Sorting machine AI Mineral separator Medical Herbs Grains ore sorter Chinese herbs AI sorting machine grains AI sorting machine
Mingde Optoelectronics Artificial Intelligence Sorting equipemnt use deep convolutional neural networks(CNN) to analyze and process material images,and through CNN partial connection,weight sharing,multiple convolution kernels and other methods,during the training process, the multi-dimensional features of materials are automatically extracted to establish a database,whose sorting effect is far better than traditional photoelectric methods.
|
Model
|
Mineral particle size (cm)
|
Capacity
(T/H)
|
Air pressure (Mpa)
|
Sorting accuracy
|
Optimized Carryover ratio
|
Power(kW)
|
Dimension(mm)
|
Weight(kg)
|
|
MAI-D4
|
3<d≤6
|
30~45
|
0.55
|
96
|
10:1
|
4.5
|
4000*2650*1760
|
2100
|
|
1<d≤3
|
10~12
|
0.55
|
|
0.5≤d≤1
|
6~8
|
0.5
|
|
MAI-D5
|
3<d≤6
|
38~52
|
0.55
|
96
|
10:1
|
5.0
|
4000*3160*1760
|
2250
|
|
1<d≤3
|
12.5~15
|
0.55
|
|
0.5≤d≤1
|
8~10
|
0.5
|
|
MAI-D6
|
3<d≤6
|
45~68
|
0.55
|
96
|
10:1
|
5.5
|
4000*3670*1760
|
2350
|
|
1<d≤3
|
15~18
|
0.55
|
|
0.5≤d≤1
|
9~12
|
0.5
|
|
MAI-S4
|
3<d≤6
|
35~50
|
0.55
|
99.8
|
20:1
|
6.0
|
4850*2650*2750
|
3000
|
|
1<d≤3
|
12~14
|
0.55
|
|
0.5≤d≤1
|
7~9
|
0.5
|
|
MAI-S5
|
3<d≤6
|
44~60
|
0.55
|
99.8
|
20:1
|
6.5
|
4850*3160*2750
|
3250
|
|
1<d≤3
|
13.5~16
|
0.55
|
|
0.5≤d≤1
|
9~11
|
0.5
|
|
MAI-S6
|
3<d≤6
|
48~75
|
0.55
|
99.8
|
20:1
|
7.0
|
4850*3670*2750
|
3500
|
|
1<d≤3
|
17.5~21
|
0.55
|
|
0.5≤d≤1
|
10.5~14
|
0.5
|
The above index is based on 15% impurity content quartz as an example,The specific index varies with the material and impurity content.
Sea pumice flower herb
Sour date seed
Walnut kernel
Core Technology
The technical characteristics of the artificial intelligence herb color sorter are as follows.
1, the herb intelligent color sorter adopts neural network artificial intelligence means.
2, the herb intelligent color sorter adopts high-resolution industrial-grade digital camera.
3, intelligent herb color sorter adopts three-dimensional multi-dimensional imaging and establishes multi-mode architecture.
4, intelligent herb color sorter adopts intelligent synchronous control of feeding system, with uniform feeding performance and high output.
5、The special mechanical structure and ash cleaning system of the artificial intelligent herb color sorter effectively reduces dust affecting the sorting system.
6, artificial intelligence herb color sorter adopts special imaging lens technology to make the light stronger, higher quality of material image collection information and better sorting effect.
As the herbs in the picking process will appear some color, shape and other objects mixed together, ordinary herb color sorter may only be able to color to separate, can not achieve the desired effect of herb sorting. Ltd. launched artificial intelligence herb color sorter can be based on color difference, shape and texture and other conditions of composite sorting, but also can be sorted broken, moldy, sprouting and other kinds of bad products, but also can be sorted glass, plastic, insect carcasses, metal and other kinds of vicious impurities.
Product feature of AI sorting machine
1,Adopt neural network in the field of sorting to solves the problem that color sorting machine can only separate according to simple criteria.
2, The sorting mode is established according to users’ sorting requirements to meet users’ diversified and personalized sorting requirements.
3, the self-developed software system and closed machine structure and the imported main internal components can adapt to the harsh environment requirements like high dust,high pollution, and high corrosion in the industry and mining area.It has a wider application range and longer life.
4,Flexible track-type material conveying system,with small drop,large output,and suitable for the sorting of more materials.
5,The vibrating feeding part and the main part of the equipment adopt a split structure to avoid the impact of vibration generated during the feeding process on the host and make the equipment operation more stable.
6, Learning mode can continuously improve the sorting effect , and the deep learning mode can be developed.
7,High intelligence,remote debugging,smart monitoring,remote service and software upgrading.
Applicable sorting ore materials
Talc, wollastonite ,calcite, quartzite
Fluorite, Potassium feldspar, Magnesite, Lithium pyroxene
Phosphate ore, Gold ore, High crystal silicon, oxide copper ore
Barite, bauxite ,lead-zinc ore and fluorite, barite lead-zinc ore
Not limited to the above ores, eye visible distinctions are applicable to AI sorting machines!
A wide range of sorting materials, can be applied to nuts, grains and cereals, Chinese herbs, dehydrated food and other materials sorting.
FAQ
Q1,Where is your factory located ?How can I visit your company?
A 1:Our factory i s located in Hefei city ,280 miles west away from Shanghai port.
All clients, from home or abroad,are warmly welcome to take a visit here.
Q2:If we are in ANHUI ,China ,can you Pick us up to your factory?
A2 Yes,of course, just tell your address and cellphone number.
Q3:can I get some Samples?
A3: No, Our products are made according to PO ,
Q4:could you please make OEM for us?
A4:Surely yes.We provide the service of replacing your logo and company name on box,if the qty is more than our limited.
Q5:What's your Payment method supported?
A5 We accept T/T,L/C,etc.
Q6:What's your Delivery time ?
A6: 7-8 weeks for FCL or LCL order.
Q8:How does your factory do regarding Quality control?
A8: Quality is very important and always be put at the first place. We insist one worker recharge 1 process.
Q9:What about your warranty?
A9: 12 months.
Q10:Can I mix different models in one container?
A10:Yes, different models can be mixed in one container, but the quantity of each model should not be less than MOQ.
Q11. How about the packing?
A11: Packing will do as customer 's requirement .We usually use Treated Fumigation-free wood case.Factory normal packing will be adopted without requirements from customer.
Q12,which is the nearest sea port ?
A12: Shanghai port
