CI185 185-020-AT-CA-M001 Acceleration Sensor
Acceleration sensor
CI 185 Series for PLC interface
Output in Velocity units as
4...20 ma signal. Loop powered
Applications
· Fans
· Blowers
· Compressors
· Pumps
Technical Specification
| Output Current |
4-20mA DC proportional to RMS velocity (mm/s) |
| Velocity Range |
See table below |
| Frequency Response |
2 Hz to 1 kHz ±10 % |
| Dynamic Range |
50g peak |
| Mounted Resonance |
5 kHz min |
| Isolation |
Base isolated |
| Operating Temp Range |
-30 to 90 ºC |
| Temperature Sensitivity |
0.08 %/ºC |
| Transverse Sensitivity |
Less than 5% |
| Supply Voltage |
12-32 Volts DC (4-20 mA) Loop powered |
| Standard Cable length |
5 meters armoured PTFE for AT and EX versions |
| Maximum Cable length |
1000 meter, for EX version see ATX009 |
| Mating Connector |
2 pin MS for CT version |
| Case Material |
Stainless steel |
| Weight |
150 gms (nominal) |
| Sealing |
IP67 |
| Mounting Torque |
8 Nm |
