Description:
The working principle of the centrifugal pump is: the centrifugal pump can send water out because of the centrifugal force. Before the pump works, the pump body and inlet pipe must be filled with water to form a vacuum state. When the impeller rotates quickly, the blades prompt the water to rotate quickly, and the rotating water flies away from the impeller under the action of centrifugal force. The water in the pump After being thrown out, the central part of the impeller forms a vacuum area. The water in the water source is pressed into the inlet pipe through the pipe network under the action of atmospheric pressure (or water pressure). In this way, continuous water pumping can be realized. It is worth mentioning here that the centrifugal pump must be filled with water in the pump casing before starting, otherwise it will cause the pump body to heat up, vibrate, reduce the water output, and cause damage to the pump (referred to as "cavitation") Cause an equipment accident!
Features
1. Advanced hydraulic model: high efficiency and wide performance range.
2. Convenient installation and maintenance: pipeline installation, inlet and outlet can be installed in any position and direction of the pipeline like a valve, installation and maintenance are extremely convenient.
3. Beautiful appearance: high-quality stainless steel jacket is used, and the appearance is beautiful.
4. Less operating and maintenance costs: high-quality mechanical seals are used, which are resistant to wear, no leakage, long service life, low failure rate, and less operating and maintenance costs.
5. Unique components, noise reduction: unique hydraulic component design, good flow performance, greatly reducing flow noise
6. Vertical structure, small footprint.
Applications:
Water pump are widely used in below systems
Water treatment systems
Industrial washing systems
Water supply systems
Firefighting systems
Cooling/air-conditioning systems
Boiler feed systems
Other industrial applications
Components in contact with water—made of SS304 or SS316
Head: 4~305m
Flow rate:0.4~240m^3/h
Phase: single phase or three phase
Power: 220V/380V
Connection: flange or threaded
Power: Pup to 110kw
Operation conditions:
For thin, clean, non-flammable and non-explosive liquid containing no solde granules and fibers -15℃~+120℃
Certificate:
CE
ISO-9001
Capacity from 2 m3/h to 72 m3/h
Head(m) from 36 to 98
Power from 1.1 kw to 30 kw
