Environmental
Parameters
|
|
|
Min Operating Temperature
|
23 °F
|
|
Max Operating Temperature
|
113 °F
|
|
Humidity Range Operating
|
10 - 95% (non-condensing)
|
|
Min Storage Temperature
|
-40 °F
|
|
Max Storage Temperature
|
158 °F
|
|
Header
|
|
|
Compatibility
|
PC
|
|
Manufacturer
|
Cisco Systems
|
|
Packaged Quantity
|
1
|
|
Product Line
|
Cisco Catalyst
|
|
Model
|
3850-24T-L
|
|
Brand
|
Cisco
|
|
Interface
Provided
|
|
|
Interface
|
RS-232
|
|
Connector Type
|
Type A
|
|
Comments
|
Management
|
|
Qty
|
2
|
|
Type
|
Network stack device
|
|
Miscellaneous
|
|
|
Compliant Standards
|
BSMI CNS 13438 Class A, CISPR 22
Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second
Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A,
GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, NOM, RoHS,
UL 60950-1 Second Edition, VCCI Class A
|
|
Authentication Method
|
Kerberos, RADIUS, Secure Shell
(SSH), TACACS+
|
|
MTBF
|
303,230 hours
|
|
Height (Rack Units)
|
1
|
|
Networking
|
|
|
Type
|
Switch
|
|
Connectivity Technology
|
Wired
|
|
Remote Management Protocol
|
CLI, RMON 1, RMON 2, SNMP 1,
SNMP 2c, SNMP 3, SSH, Telnet
|
|
Compliant Standards
|
IEEE 802.1D, IEEE 802.1p, IEEE
802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE
802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
|
|
Status Indicators
|
Port duplex mode, Port
transmission speed, Status, System
|
|
Ports Qty
|
24
|
|
Features
|
Access Control List (ACL)
support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), Cisco
StackPower technology, Cisco StackWise-480 technology, DHCP snooping, Dynamic
ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient
Ethernet, Flexible NetFlow (FNF), IGMP snooping, IPv4 support, IPv6 support,
Layer 3 load balancing, Link Aggregation Control Protocol (LACP), MLD
snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation
Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid
Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP)
support, Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), STP
Root Guard, Syslog support, Trivial File Transfer Protocol (TFTP) support,
Trunking, Uni-Directional Link Detection (UDLD), Virtual Route
Forwarding-Lite (VRF-Lite), VLAN support
|
|
MAC Address Table Size
|
32000 entries
|
|
Stackable
|
Stackable
|
|
Subcategory
|
Network hubs and switches
|
|
Advanced Switching
|
Layer 3
|
|
Manageable
|
Yes
|
|
Form Factor
|
Desktop, Rack-mountable
|
|
Jumbo Frame Support
|
9198 bytes
|
|
Subtype
|
Gigabit Ethernet
|
|
Power Device
|
|
|
Frequency Required
|
50/60 Hz
|
|
Power Provided
|
350 Watt
|
|
Installed Qty
|
1
|
|
Max Supported Qty
|
2
|
|
Nominal Voltage
|
AC 120/230 V
|
|
Power Redundancy
|
Optional
|
|
Power Redundancy Scheme
|
1+1 (with optional power supply)
|
|
Type
|
Internal power supply
|
|
Service
|
|
|
Support Details Type
|
Technical support
|
|
Support Details Full Contract
Period
|
90 days
|
|
Support Details Service
Included
|
Consulting
|
|
Slot Provided
|
|
|
Type
|
Expansion slot
|
|
Total Qty
|
1
|
|
Free Qty
|
1
|
|
Software
|
|
|
Type
|
Cisco IOS LAN Base
|
|
Dimensions
& Weight
|
|
|
Width
|
17.5 in
|
|
Depth
|
17.7 in
|
|
Height
|
1.8 in
|
|
Weight
|
15.87 lbs
|
|
Service &
Support
|
|
|
Type
|
Limited lifetime warranty
|
|
Capacity
|
|
|
Type
|
Switched virtual interfaces
(SVIs)
|
|
Value
|
1000
|
|
Flash Memory
|
|
|
Installed Size
|
2 GB
|
|
Performance
|
|
|
Type
|
Switching capacity
|
|
Value
|
88 Gbps
|
|
Ports
|
|
|
Qty
|
24
|
|
Type
|
10/100/1000
|
|
RAM
|
|
|
Installed Size
|
4 GB
|
