C6816-X-LE Overview
The Cisco Catalyst 6840-X series switch is a 2RU fixed backbone switch in the Cisco Catalyst 6800 family. The 6840-X is based on the Cisco Catalyst 6800, with more than 3000 features and maturity of software code. The Cisco Catalyst 6840-X is the smallest Multiprotocol Label Switching (MPLS) aggregator or Instant Access controller in the Cisco 6800 Catalyst Family.This 10G/40G-ready platform is ideal for those who want to introduce premium 10G services in small or midsize campus backbones. This unique platform offers 10G port density, full IPv4/IPv6 and MPLS/VPLS functionality with large table sizes (up to 256,000 FIB entries). With a full suite of L2/L3, virtualization, security, multicast, IPv6, application visibility, smart operations, and rich media services, the Cisco Catalyst 6840-X delivers unprecedented capabilities on day one. This platform also runs on the same architecture as the Cisco Catalyst 6500 Supervisor Engine 2T and therefore offers stability with proven operating system software.
C6816-X-LE Specification
|
General
Information
|
|
|
Manufacturer:
|
Cisco Systems, Inc
|
|
Manufacturer Part Number:
|
C1-C6816-X-LE
|
|
Manufacturer Website Address:
|
http://www.cisco.com
|
|
Brand Name:
|
Cisco
|
|
Product Line:
|
Catalyst
|
|
Product Series:
|
6840-X
|
|
Product Model:
|
6816-X-LE
|
|
Product Name:
|
Catalyst 6816-X-LE Layer 3 Switch
|
|
Product Type:
|
Layer 3 Switch
|
|
Interfaces/Ports
|
|
|
Uplink Port:
|
Yes
|
|
Modular:
|
Yes
|
|
Stack Port:
|
No
|
|
Port/Expansion Slot Details:
|
16 x 10 Gigabit Ethernet Expansion Slot
|
|
Media & Performance
|
|
|
Media Type Supported:
|
Optical Fiber
|
|
Ethernet Technology:
|
10 Gigabit Ethernet
|
|
Network Technology:
|
10GBase-X
|
|
I/O Expansions
|
|
|
Number of Total Expansion Slots:
|
16
|
|
Expansion Slot Type:
|
SFP+
|
|
Number of SFP+ Slots:
|
16
|
|
Network & Communication
|
|
|
Layer Supported:
|
3
|
|
Management & Protocols
|
|
|
Manageable:
|
Yes
|
|
Power Description
|
|
|
Power Source:
|
Power Supply
|
|
Redundant Power Supply Supported:
|
Yes
|
|
Physical Characteristics
|
|
|
Desktop
|
|
|
Compatible Rack Unit:
|
2U
|
|
Form Factor:
|
Rack-mountable
|
|
Height:
|
3.50" (88.90 mm)
|
|
Width:
|
17.35" (440.69 mm)
|
|
Depth:
|
21.52" (546.61 mm)
|
|
Weight (Approximate):
|
10.90 kg
|
|
Warranty
|
|
|
Limited Warranty:
|
1 Year
|
