WS-C3650-48FQ-S Overview
The Cisco Catalyst 3650 series is the enterprise-class standalone and stackable access-layer switch that provides the foundation for full convergence between wired and wireless on a single platform. The Cisco Catalyst 3650 takes advantage of the Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. It can help you increase wireless productivity and reduce your TCO.
WS-C3650-48FQ-S Specification
Technical Specifications
Capacity
TypeVirtual interfaces (VLANs)Value1000
Dimensions & Weight
Width17.5 inDepth19.1 inHeight1.7 inWeight17.2 lbs
Environmental Parameters
Min Operating Temperature23 °FMax Operating Temperature113 °FHumidity Range Operating5 - 96% (non-condensing)Min Storage Temperature-40 °FMax Storage Temperature158 °F
Flash Memory
Installed Size2 GB
Header
CompatibilityPCManufacturerCisco SystemsPackaged Quantity1Product LineCisco CatalystModel3650-48FQ-SBrandCisco
Interface Provided
Qty48TypeManagement (mini-USB)Connector TypeType BCommentsManagementPoE Power30 W
Miscellaneous
Rack Mounting KitIncludedCompliant StandardsBSMI CNS 13438 Class A, CISPR 22 Class A, CISPR 24, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024, FCC Part 15 A, GOST, ICES-003 Class A, IEC 60950-1 Second Edition, ISO 7779, KCC, KN22 Class A, KN24, NOM, RoHS, UL 60950-1 Second Edition, VCCI Class AAuthentication MethodRADIUS, Secure Shell (SSH), TACACS+MTBF383,760 hoursHeight (Rack Units)1Color CategoryBlack
Networking
TypeSwitchConnectivity TechnologyWired/WirelessRemote Management ProtocolCLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2c, SNMP 3, SSH, TelnetCompliant StandardsIEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3zStatus IndicatorsActive, PoE, Port duplex mode, Port transmission speed, Status, SystemPorts Qty48FeaturesAccess Control List (ACL) support, ARP support, DHCP snooping, Dynamic ARP Inspection (DAI), EIGRP Stub Routing, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping, Layer 2 switching, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), Trunking, Uni-Directional Link Detection (UDLD), VLAN supportRouting ProtocolOSPF, RIP-1, RIP-2, RIPng, Static IP routingMAC Address Table Size32000 entriesStackableStackableSubcategoryNetwork hubs and switchesPower Over Ethernet (PoE)PoE+Advanced SwitchingLayer 3ManageableYesForm FactorDesktop, Rack-mountableJumbo Frame Support9198 bytesSubtypeGigabit EthernetPoE Budget775 W
Performance
TypeSwitching capacityValue176 Gbps
Ports
Qty48Type10/100/1000 (PoE+)
Ports (2nd)
Qty4Type10 Gigabit SFP+
Power Device
Frequency Required50/60 HzPower Provided1025 WattInstalled Qty1Max Supported Qty2Nominal VoltageAC 120/230 VPower RedundancyOptionalPower Redundancy Scheme1+1 (with optional power supply)TypeInternal power supplyHot-PlugHot-plug
RAM
Installed Size4 GB
Service
Support Details TypeTechnical supportSupport Details Service IncludedPhone consultingSupport Details Full Contract Period90 days
Service & Support
TypeLimited lifetime warranty
Service & Support Details
Response TimeNext business day
Slot Provided
TypeStacking Module slotTotal Qty1Free Qty1
Software
TypeCisco IOS IP Base
