Class P LED driver 60w Dimmable LED Driver 12v 24v Manufacturers

SMT-012-060VTH is the PWM output & High PF>0.99 & High efficiency>87% paired with relative junction box. Typically smaller, lighter and less expensive than magnetic drivers, an dimmable led driver may be preferred for installations where space is at a premium.


  • Size188*90*26mm / 165*92*41mm
  • CertificationUL, cUL, FCC, Class P, Type HL
  • Dimming modeTriac Dimming
  • Working ModeConstant Volatge
  • Output Voltage12V & 24V DC
  • Input Voltage100-277V AC

Class P 60w Dimmable LED Driver 12v 24v


Smarts Electronics' SMT-012-060VTH 12v 60w dimmable led driver is the perfect choice for use in Schools, Hospitals, and Shopping Malls or for any commercial application that 277V is present. The led driver dimmable are paired with relative junction box. This unit can be operated with input current ranging from 100 to 277 VAC and will output 60 watt 12 Volt DC current at 5.0 amps. This led driver dimmable features an IP20 rated design, making it suitable for indoor use and includes integral short circuit and overload protection that will shut down the unit in case of faults and overloads to protect the unit and connected equipment from damage.


  Specifications


model

SMT-012-060VTH

SMT-024-060VTH

Output

DC Voltage

12V

24V

Voltage Accuracy

±0.5V

±0.5V

Voltage Regulation

±0.5%

Rated current

5.00A

2.50A

Load Regulation

±1%



Rated power

60W

60W

Input

Voltage Range

100-277V AC

Frequency Range

47~63HZ

Power Factor ( Typ.)

0.98@120VAC  0.95@277VAC

0.98@120VAC  0.95@277VAC



Full Load Efficiency(Typ.)

>83%

>83%

AC Current(Typ.)

0.9A/110VAC

Inrush Current (Typ.)

14A, 50%, 780us

Leakage current

<0.50mA

Over temperature

100℃±10℃ shut down o/p voltage, automatically recover after cooling.



Short Circuit

shut down o/p voltage, re-power on to recover after fault condition removed

Over Loading

≤120% Hiccup mode,recovers automatically after fault condition is removed

Over voltage

<140VAC(90~135V) , <285VAC(170~277V)

Environment

Working TEMP.

-40~+60℃

Working Humidity

20~90%RH,non-condensing

Storage TEM.,Humidity

-40~+80℃,10~95%RH

TEMP.coefficient

±0.03%/℃(0~50℃)

Vibration

10~500Hz,2G 10min./1 cycle,period for 60min.

each along X,Y,Z  axes

Safety&EMC

Safety standards

UL8750+UL1310

Withstand voltage

I/P-O/P:3.75KVAC

Isolation resistance

I/P-O/P:100MΩ/500VDC/25℃/70%RH

EMC EMISSION

FCC Part 15 B

EMC IMMUNITY

Compliance to EN55015; EN61000-4-2,3,4,5,6,8,11, EN61547

Alight industry level (surge4KV)

Others

Weight

About 1.1Kg

Size

188*92*26mm(L*W*H)

packing

10PCS/CTN

 (L*W*H)

Notes

1. All parameters NOT specially mentioned are measured at 110V/277VAC input , rated load and

25℃of ambient temperature.

2. Ripple& noise are measured at 20MHz of bandwidth by using a 12”twisted

 pair-wire terminated with a 0.1uf &47uf parallel capacitor.

3.  Tolerance:includes set us tolerance,line regulation and load regulation .

  Label   60w led driver


Triac dimmable led driver
dali led power supply
0-10v led driver
slim size led driver


  Features of 60w led driver

  • Output constant voltage
  • Input voltage range 100-277VAC
  • Built-in PFC function / PF>0.97
  • Efficiency >85% / Dimming range: 0~100%
  • Protections:short circuit/over voltage/over heat
  • PWM output, does not change the color index
  • IP20 design for indoor installations
  • Cooling by free air convection / Flicker-free
  • Work with leading edge and trailing edge TRIAC dimmers
  • Strong compatibility, flicker-free dimming
  • Suitable for LED lighting and moving sign applications
  • Compliance to worldwide safety regulations for lightings.
  • Compatible with Forward phase, Reverse phase, Triac, MLV, ELV Dimmers
  • 7 years warranty



  Dimming Operation for 60 watt led driver


Output constant current level can be adjusted through input terminal of the AC phase line(L) by connection a triac dimmer. Compatible with Leading edge or trailing edge triac dimmers, but trailing edge dimmers work better..

Please try to use dimmers with power at least 1.5 times as the output power of the driver.


  Simple connection for Triac dimmable led driver

dimmable led driver
