Acrylic Paper Cardboard Fabric Laser Cutting Engraving Machine
PRODUCT PARAMETER
|
NO.
|
Model
|
Lz-1610 Double Head
|
|
1
|
Working Area
|
1600x1000mm
|
|
2
|
Packing Size
|
2300x1650x1300mm
|
|
3
|
Working Table
|
HoneyComb Table
|
|
4
|
Laser tube type
|
CO2 sealed laser tube
|
|
5
|
Cooling System
|
Water Chiller CW5200
|
|
6
|
Control System
|
RUIDA6442G
|
|
7
|
Software
|
RD Work
|
|
8
|
Software supported
|
CorelDraw,Photoshop,AutoCAD,TAJIMA
|
|
9
|
File output mode
|
2.0 USB interface
|
|
10
|
Laser power
|
60~150W for option
|
|
11
|
Motor
|
Leadshine Stepper motor
|
|
12
|
Resolution
|
1,000--10,000 dpi
|
|
13
|
Machine Power
|
<3,000W
|
|
14
|
Minimum Character Size
|
English1.0×1.0mm
|
|
15
|
Engraving speed
|
0-40000mm/min
|
|
16
|
Cutting speed
|
0-10000mm/min
|
|
17
|
Reposition Accuracy
|
0.01mm
|
|
18
|
Graphic format supported
|
BMP, PLT, DST, DXF, AI
|
|
19
|
Voltage
|
AC220V/110V,50HZ/60HZ
|
Laser
cutting makes everything possible.
Laser cutting makes everything possible. The paper laser cutting machine is an unparalleled method of paper processing. The laser enables high-precision contouring and the material is not subject to mechanical stress. Instead of burning the paper during the laser cutting process, it suddenly evaporates.
APPLICABLE MATERIALS
wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.
APPLICATBLE INDUSTRY
advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry.
DOUBLE LASER HEAD
Dual laser head are freely assigned and intelligently follow your direction.When is full layout,each laser head will be programmed to find its own area intelligently.When it is odd number layout ,one of cutting head will stop working by intelligent coordination.
