Color Coated Galvanized Steel Coil
WanJuan Steel supplies a variety of prepainted steel sheet and coil products to meet customer needs. Our value-added service capabilities include slitting, shearing, stretcher leveling, blanking and metallurgical support.
Product Information
|
Standard
|
JIS G3322 CGLCC ASTM A755 CS-B
|
Surface coating color
|
RAL colors
|
|
Back side coatingcolor
|
Light grey ,white and so on
|
Package
|
export standard package or as request
|
|
Type of coating process
|
Front: double coated&double drying. Back: double coated&double drying, single-coated&double drying
|
|
Type of substrate
|
hot dipped galvanzied, galvalume, zinc alloy, cold rolled steel, aluminum
|
|
Thickness
|
0.11-2.5mm
|
Width
|
600-1250mm
|
|
Coil Weight
|
3-9Tons
|
Inside Diameter
|
508/610mm
|
|
Zinc Coating
|
Z50-275g/㎡
AZ30-150g/㎡
|
Painting Coating Thickness
|
Top: 8-35 um
Back: 3-25 um
|
|
Painting Color Style
|
2/1,2/2
|
Length
|
As,require
|
|
Coating introduction
|
Top paint: PVDF, HDP, SMP, PE, PU
|
|
Prime paint: Polyurethane, Epoxy, PE
|
|
Back paint: Epoxy, Modified polyester
|
Our Service
-
Heavy Gauge Slitting
-
Steel Coil Slitting
-
Steel Sheet Cut-to-Length
-
Electro cold Rolled & Hot Dipped Coating
-
Steel Sheet & Plate Painting
-
Finishing Services
FAQ
why our steel?
We are China well known steel sheet manufacturer and supplier. Cooperated with professional and strength manufacturer,we can provide metal products that meet your requirements.
whats the biggest advantage?
We saves you time and money. With our cold rolled steel sheet you can achieve greater yields, improved equipment usage and fewer work hours to manufacture your parts.
what services do we provide?
We can provide customized service including slitting,steel sheet & plating painting,hot dipped coating,finishing treatment,custom size options. Please feel free to send us your requirements,we will reply very soon.
How do we package the products?
Triple packaging (anti-rust paper + plastic film + corrugated paper), fixed with fumigated wooden pallets, which can effectively protect the product from corrosion during ocean transportation.
When do we deliver the products?
Standard products within 15 days, customized products within 20-30 days.
