1、Import PC material , Long last usage
2、Colorful rings available, ODM service available,Laser print customer LOGO
3、Constant current internal driver, safety guaranteed
4、High PF value over 0.9 for decrease of electricity loss
5、High quality PCB for good heat dissipation
6、No flicker,no delay, Instant on/off
Model
|
Size (mm)
|
Watt
|
Input Voltage
|
SMD LED
|
Material
|
PF
|
CRI
|
Cap
|
Beam Angle
|
Light efficiency
|
T8-60CM-10W-F
|
Φ26*L600
|
10w
|
AC85-265V
|
SMD2835
|
Full PC material
|
>0.92
|
>80
|
G13
|
160°
|
100LM/W or more higher
|
T8-120CM-18W-F
|
Φ26*L1200
|
18w
|
AC85-265V
|
SMD2835
|
Full PC material
|
>0.92
|
>80
|
G13
|
160°
|
100LM/W or more higher
|
|
T8-150CM-25W-F
|
Φ26*L1500
|
23w
|
AC85-265V
|
SMD2835
|
Full PC material
|
>0.92
|
>80
|
G13
|
160°
|
100LM/W or more higher
|
Warning: Switch off power supply BEFORE COMMENCING WORK!
Step1. Remove the fluorescent lamp
Step2. Cut off all wires which connected to inductive ballast or electrical ballast
Step3. Install LED tube into lighting fixture with below one(Type I or Type II) wiring method refer to the label on the tube
Step 4.Switch on power
Perfect Used for factory, office, parking, shopping mall and Hotel lighting etc
