Environmental testing:
Through RoHS Directive 2011/65EU and refer to IEC.62631.Ed1111/54/CDV
Inspection standard for the use of safe substances
Electrical characteristics:
A.20 volt AC. Maximum 2 ampere withstand voltage volts
B. Withstand voltage test: less than 0.5 amps 1000 volts DC / one minute
C. Insulation resistance: 1000 volts DC / one minute, greater than 500 million ohms
D. According to the touch resistance: no more than 20M (milliohms)
Gold plating inspection:
According to MIL-G-45204C standard specifications, TYPEII is at least 99% pure gold
Level C+ (knop hardness range 130-250)
Level 1 (minimum 50U "thickness")
Mechanical characteristics:
A. Tensile test - wire to socket tension strength of at least 1 minute 2 pounds (89N)
B. Endurance test - plug test more than 2000 times
Material and surface treatment:
A.PLUG raw material: PC fire rating 94v-2 & 94v-0 (uL No.E239590)
B. Gold piece: phosphor bronze material
a. High-strength copper alloy [JIS C5191R-H (PBR-2)] standard material
