Support paper end detection, seam detection, black label detection, open cover detection and paper removal detection
Support large diameter paper roll and folded paper
Support thermal label/receipt printing
Specification:
|
Item
|
CP410
|
|
Printing Method
|
Thermal printing
|
|
Printing Speed
|
150mm/s(max)
|
|
Resolution
|
203dpi,8dots/mm
|
|
Character Set
|
Support User-defined characters
GB18030 24X24
ASCII 9X17,12X24
|
|
Graphics printing
|
Support dots printing with different densities,support raster
bitmap print,support downloaded bit image print
|
|
Code pages
|
Support simplified&traditional Chinese ,English,Japanese
and other 45 kinds of international character sets.
|
|
Barcode type
|
UPC-A;UPC-E;JAN13(EAN13);JAN8(EAN8);CODABAR;
ITF;CODE39;CODE93;CODE128;QR CODE;
|
|
Interface
|
USB+Bluetooth/USB+Bluetooth+RS232
|
|
Power
|
DC 24V/2.5A
|
|
Cashbox control
|
RJ11-6P6C Socket,24V
|
|
Work environment
|
Temperature: 0~45ºC; Dampness:10~80%
|
|
Storage environment
|
Temperature: -10~60ºC; Dampness:10~90%
|
|
Paper Width
|
25.4-110mm
|
|
Printing width
|
220mm(MAX)
|
|
Paper cutting
|
manual
|
|
Dimension(L*W*H)
|
175mmx95mmx95mm
|
|
TPH life
|
100km
|
|
Paper type
|
Thermal receipt/label paper
|
|
|
Windows(WIN7/WIN8/WIN10/Vista/XP/2000)
Ubuntu 12.04 32/64 Ubuntu 14.04 32/64 MAC OS
|
|
|
Compatible with ESC/POS/JPL/TSPL/CPCL/EPL/ZPL command set
|
