CSN-310 3inch Direct Thermal Label Printer

24VDC, USB/Blueooth interface, 40-80mm paper width

The CSN-310 thermal label printer offers flexible space-saving design. with 127mm per second fast print speed, auto detection and calibration of media, tool-less print head and platen replacement. With support for media widths up to 80mm, the CSN-310 is ideal for many application






Specification:

Model		CSN-310
Print	Print mode	Thermal line printing
	Printing speed	127mm/s,150mm/s（Option）
	Effective printing width	72mm
	Resolution	203dpi(8dots/mm)
Paper spec.	Midia Type	Continuous, gap, black mark, fan-fold
	Midia Thickness	0.10-0.15mm
	Midia Width	40-80mm
	Midia height	Max.500mm
	Media Gap	Min.2mm
Paper supply method		Auto-feed /Drop-in easy loading
Reliability	TPH	50km(12.5% print ratio)
Detection		Cover opend ,paper ending,paper gap
Barcode	1D	EAN-13,EAN-8,CODE39,CODE93,CODE128,CODEBAR,ITF,UPC A,UPC-E
Barcode	2D	QR CODE,PDF417
Text and graphic support		Figure, symbol, graph, curve, icon, multi-languages
Command set		ESC/POS,TSPL
Driver/SDK		Windows Driver, Linux Driver, Android SDK
Interface	Wire	USB2.0
Interface	Wireless	Bluetooth (optional)
Power supplier		24V,2A/2.5A
Accessories		Power supplier ,USB cable,user manual,Label editor app
Temperature		Operating:0℃~50℃
Temperature		Storage:-20℃ ~ 60℃
Humidity		Operating:10%RH~80%RH
Humidity		Storage:10%~90%RH
