80MM thermal receipt POS printer with auto cutter
CSN-80L pos receipt printer is a compact,fast and advanced receipt pos thermal printer, and barcode printer. enabling you to produce high quality receipts quickly and easily. With an easy maintenance cutter and patented long life printing (LLP) technology, capable of extending print life to over 100km.Features include drop-in paper loading, RS232,USB two ports, auto cutter and a long life thermal print head.
Feature:
1). High printing speed, up to 250mm/s, easy to maintain, improve work efficiency.
2). Low noise, high speed image&characters printing.
3). Easy paper loading, with auto cutter, partial cut.
4). Multiple interface
5). Compatible with EPSON ESC/POS command sets.
6). Support paper out alarm and print prompt.
7). Driver compatible: Win 2000/WinXP/Windows7/Windows10/Linux.
Specification:
| Model No. |
CSN-80L |
| Print Method |
Thermal line printing |
| Print Speed |
Max.250 mm/sec |
| Effective Print Width |
72mm |
| Thermal paper roll |
Paper width:80mm |
| Max.80mm(O.D) |
| Paper thickness:0.055-0.09mm |
| Resolution |
203dpi |
| Reliability |
TPH life:100km |
| Cutter life:1 million cuts or more |
| Character size |
(ANK Character):12×24 dots,1.5(width)×3.00(height)mm |
| (Jan/traditional form):24×24 dots,3.00(height)×3.00(high)mm |
| Characters Set |
ANK:Font A:12x24dots |
| Font B:9x17dots |
| Jan/traditional form:24x24dots |
| Barcode type |
UPC-A,UC-E,JAN13(EAN13),CODABAR,ITF,CODE39,CODE93,CODE128 |
| PDF417,QR Code |
| Interface |
RS232C+USB+LAN/RS232+USB/USB+LAN/USB+LAN+WIFI |
| Auto-Cutter |
Full cut and Partial cut by command |
| Cashbox Control |
24V/1A |
| Power supply |
DC24V/2.0A |
| Printing command |
Compatible with ESC/POS command set |
| Dimension (WxLxH) |
148x198x145mm |
| Work environment |
Temperature 0°C~45°C;Relative humidity:10%~80% |
| Store environment |
Temperature-10°C~60°C;Relative humidity:10%~90% |
| Driver/SDK |
Windows Driver, Linux Driver, Android SDK, Windows SDK |
Company Information:
We are a professional manufacturer of thermal printers since 2011, with the ISO9001, CE, Rohs and FCC certificates passed. Our main products are battery powered portable mobile printer, impact dot matrix printer, thermal panel printer, kiosk thermal printer, POS thermal printer and thermal label printer, etc. We have a wealth of in dependent research and experience, which can effectively meet different customers ODM requirements and help achieve printing simply, efficiently and economically. Currently, Our products are exported to Southeast Asia, South Asia, South & North America, Middle East and Europe, etc.
Certificates:
Our Services:
FAQ:
Q: About samples
A: Samples are available for testing.
Q: Delivery date.
A: All the printers for samples are in stock, can ship it within 2 days after payment received. For bulk order
delivery date approximately 2 weeks.
Q: Payment terms
A: Paypal, western union, T/T in advance.
Q: Warranty
A: One year warranty. During warranty period, the damage caused by non-human factor, CASHINO will be
responsible for the free repair. Overdue warranty period, CASHINO will continue to provide services with
reasonable price to the customer.
