Plane Specifications
|
Width
|
930mm ~ 1130mm
|
|
TCK
|
PU/PIR:40mm~300mm; Rock Wool+PU/PIR:40mm~200mm
|
|
Length
|
≤26m
|
|
Steel Plate Specifications
|
Material
|
PPGI,304/316SS
|
|
TCK
|
0.4mm~0.8mm
|
|
Coating
|
PE,HDP,PVDF
|
|
PU
|
Water Absorption
|
≤3%
|
|
Heat Conductivity Coefficient
|
0.018~0.024
|
|
Heat-resisting Range
|
-185℃~+110℃
|
Excellent Insulation Performance
Physical unclonable function (Puf)core material with excellent heat preservation performance, combined with exquisite and reasonable insertion and installation node design, ensures the sealing and heat insulation effect of the wholeclean room enclosure system.
Good Fire Resistance
Polyurethane is a thermosetting resin that forms a protective coking layer during combustion without melting and dripping like EPS and XPS.Compound with metal surface can further improve its flame retardant performance.
Plate Durable
High quality painted steel plate or stainless steel plate with excellent strength and corrosion resistance.The obturation rate of polyurethane rigid foam is more than 90% and the water absorption rate is less than 3%.The properties of the board can be maintained in good condition for a long time.
Strict Environmental Protection Standards
The selection and processing of polyurethane boards strictly follow the national and industrial environmental standards.The plate is not easy to breed bacteria and parasites in the process of use, which can adapt to various complex situations and strict environmental requirements in theclean room industry.
Easy And Quick Installation
The prefabrication of sheet metal in factories and the mature design of installation system make the field installation easier and faster, greatly shorten the construction period, reduce labor cost and material loss.
Technology
PUF Cleanroom Panel
International advanced six - component pentane foam technology is adopted.Pentane foaming is an advanced fluorine-free foaming technology that eliminates the original fluorine-containing F11 and 141B foaming agents to protect the earth's ozone layer.
Rock wool Clean Room Sandwich Panel
Rock wool referred to as RW, is high quality basalt, diabase as raw materials, through 1400℃ high temperature melting, high-speed centrifugal pull fiber, and then add binder, dustproof oil, hydrophobic agent and other small amount of additives made.Rock wool range of heat -60℃~+500℃, fire grade up to A class.Rock wool is a man-made mineral fiber, which is completely different from natural mineral fiber asbestos, and will not cause harm to human health.
Color Coated Steel Plate
The strip is used as the base material (such as hot galvanized board and aluminized zinc board), and the surface is coated with polymer coating, such as polyester (PE), silicon-modified polyester (SMP), high-durability polyester (HDP), polyvinylidene fluoride (PVDF), etc.Wiskind has established strategic partnerships with Shanghai baosteel, bothger, yehui, united iron & steel, masteel and Nippon and other well-known enterprises. Its special high-quality painted boards can be used for ten years in high temperature, high humidity and acid and alkali corrosion environment to meet the special needs of the food industry.
Stainless Steel Plate
Adopt high quality 304 or 316 stainless steel raw material to ensure stable product quality.The surface of the plate is covered with special protective film of stainless steel to prevent the damage caused by transportation, installation and tearing.Stainless steel bonding surface after special treatment, so that the plate andPUF cleanroom panelsrate of 95%, effectively avoid the bond is not firm phenomenon.
