Cutting-Edge Customized Forklift Battery Pack for Superior Performance

We welcome customized order to us, more forklift battery models available: 24V 36V 48V 80V and high volt battery, capacity customized from 100AH-1000AH





Quick details




1,Battery model :80V600AH (built in BMS),can realize real time monitor

2,Material:Lifepo4 battery

3,Shell:Q235 d=3-5mm

4,Full harness and plug +4.3" display screen

5,Heating and remote module optional

6.Eight protect function: Overcharge/overdischarge protect,overcurrent protect,overtemperature protect,overvolt protect ,shortcircuit protect etc...



model

QH80V600Ah

volt arrange

62.5V-91.25V

rated volt

80V

rated capacity

600Ah

discharge current

400A

discharge temperature

-20℃-60℃

charge current

100-200A

charge temperature

-0℃-45℃

size

customized

weight

around 450kg

communication

CAN

service life

5Y

screen

EA4.3inch screen

parallel

25S3P



FAQ




Q1: what is your MOQ?

A: Only one sample available.
Q2: what is your guarantee life for the battery?

A: 5Y warranty for lifepo4 built in bms battery .

Q3. Can you explain in detail how you match cells for a battery pack before you assembling the pack?

A: We will do the following things before assembling the pack:
a. Select capacity: same capacity rate cells for one pack
b. Measure the voltage: same voltage cells for one pack(difference is under 0.02 v per cell)
c. Measure the inner resistance: same IR cells for one pack (difference is under 1 mOhm)
All above steps are very strict to make sure the pack performance is perfect.

Q4: Before order, can I have samples for testing?

A: Yes, we can provide you samples for testing firstly.

Q5: What kind of environment should lithium batteries store?

A: -40°C~50°C, 65±20%RH storage for a long time(>3 months) and the storage condition shall be:<35°C , 65±20%RH

Q6: What certificate do you have?
A:CE,FCC,CB,KC,SGS, Rohs, IEC62133 MSDS & UN38.3..

Q7: Can you ship the battery products to our country?
A: Yes, for one sample ,we can quote door to door . for more quantity, we will quote FOB China
Q8: What is your payment and delivery items & time?

A: 1. Payment items: By T/T , 30% for deposit, and balance all before shipment. For small amount, we also accept payment via Western Union or Alibaba .
2. Delivery Items: we can ship the batteries by sea, by air, by UPS, DHL, TNT, FEDEX and some special transportation lines.
3. Delivery time: Generally, it will take 15 days after receiving your advanced payment.
