0.05-0.25mm thickness Pneumatic Welding Machine for 18650 Cylinder Cell Welder
SPECIFICATIONS
Dual pulse welding:
This TOB-PS250 Spot welding machine mainly used for 18650 battery pack tab welding, it can weld Nickel tab thickness from 0.05-0.25mm. You can also choose our other model according to your tab Thickness.
Dual pulse welding, the first pulse is used to the workpiece surface coating and oxide removal, and make the contact place in welding electrode produce slight deformation, improve the effective contact area, the second pulse is used to ontology metal welding, can effectively promote the quality of welding and reducing welding spatter.
|
Model
|
TOB-PS250
|
|
Power
|
15KVA
|
|
secondary side of welding current
|
3000A
|
|
Secondary no-load voltage
|
5.5V
|
|
Input voltage
|
220V
|
|
Input frequency
|
50Hz
|
|
Working pressure
|
0.5-0.8Mpa
|
|
Welding pulse
|
Single pulse, double pulse, multiple pulse programmable
|
|
Welding control model
|
Foot switch control
|
|
Weight
|
30KG
|
|
Sizes(L*W*H)
|
400*220*360mm
|
PRODUCT DISPLAY
PACKAGE
