advanced core patented technology
|
|
high safety, triple anti-pinch
|
|
high stability, optimize the mechanism structure
|
|
long life, longer than 10 million times
|
|
|
|
|
|
|
|
|
|
modular design, easy maintenance
|
|
|
|
|
|
|
All-around Pedestrian Safety Protection
Triple anti-clamping
With double anti-clamping technologies such as mechanical anti-clamping and anti-collision by advanced electric current detection, the half height glass turnstile can protect pedestrian safety more comprehensively.
Over-force feedback control
When the gate is momentarily subjected to an impact force beyond the safe range, the half height glass turnstile can be slowly pushed for a certain distance to buffer the impact force on the mechanism and the reverse impact force on pedestrians.
Anti-electric shock
All electric modules are designed to operate under the safety voltage of 24V, and configured with residual current protective device to prevent pedestrian from being injured by electric shocks.
Turnstile opens when power failure
With the independently developedadvanced mechanical structure, the system will automatically unlock the gate when the power is off, and the gate can be manually pushed to open, which is convenient for pedestrian evacuation.
Emergency open
The half height glass turnstile equips with emergency escape control device, to make the system automatically open the gate to evacuate pedestrian.
Advanced & Intelligent Turnstile Core Technology
Advanced core logic algorithm
The half height glass turnstile adopts advanced servo control system and DSP+ARM motor control technology, combined with CMOLO's original motor control algorithm, to achieve precise control and positioning of the obstacle and maintain stable performance.
Strong mechanism structure
The lossless modular mechanism structure independently developed by CMOLO and the full CNC processing technology ensure the precision, strength, concentricity of the mechanism, and the transmission ratio are accurate, efficient and stable, which can precisely control the rotation angle of the gate and reduce the loss to ensure the reliability of the mechanism, and enhance the service life of the mechanism.
Long service life
CMOLO has independently developed an advanced lossless mechanism structure, and is equipped with a high-quality brushless DC motor (core of the mechanism), so that the half height glass turnstile has a long service life.
Customization
| Appearance |
Cabinet size, material and surface treatment process etc. of turnstile can be moderately customized. |
| Lane width |
The maximum lane width of turnstile is 900mm, and the cabinet length can be increased accordingly |
Material of the gates
|
Tempered glass / acrylic / polycarbonate/ 304 grade stainless steel, and color can be customized. |
Direction Indicator
|
The shape of direction indicator can be customized. |
| System integration |
Integrate with access control system, human body temperature measurement system, ticketing system, time attendance system, visitor system etc.
Integrate with QR code, face, fingerprint, ID/IC card, passport identification system etc.
Integrate with card collection system, and customize card collection device
Integrate with radar system to automatically open the gate when pedestrian approaches, and automatically closes the gate when pedestrian leaves.
|
