D60 Ring Lock High Load Shoring Scaffolding Standard / Vertical
Product Details:
|
Code
|
Description
|
Material
|
Size
|
Weight (kg)
|
Weight (lbs)
|
|
D60RS.S.300
|
3.00M Standard
|
Ø60.3x3.5mm; Q235-Q355
|
3000mm (9'10")
|
18.93
|
41.74
|
|
D60RS.S.250
|
2.50M Standard
|
2500mm (8'2")
|
15.93
|
35.13
|
|
D60RS.S.200
|
2.00M Standard
|
2000mm (6'7")
|
12.94
|
28.53
|
|
D60RS.S.150
|
1.50M Standard
|
1500mm (4'11")
|
9.94
|
21.92
|
|
D60RS.S.100
|
1.00M Standard
|
1000mm (3'3")
|
6.94
|
15.30
|
|
D60RS.S.050
|
0.50M Standard
|
500mm (1'8")
|
3.95
|
8.71
|
Features:
Tube Dimension: O.D60x3.5mm. Other tube thickness 4.0mm/3.25/3.0mm is also available by request.
Spigot Size: O.D 50x3x250mm
Steel Tube Grade: Q235-Q355
Rossette Distance: 500mm
Surface Finishing: Hot dip Galvanized; Powder Coated, Painted
Quality Standard: EN12810 / BS1139
Welding Process: Automatic welding
