Specifications:
Product size: 85*58*38 mm
Case material:aluminum
Net weight/pc: 165g
Input voltage: 100-240v
output voltage: 12v
Frequency: 47-63Hz
Output power: 25W
output current: 2.08A
Features:
Competitived price and high reliability
105 °C Output capacitor
AC input power suitable for the world
High efficiency and low operation temperature
Soft-start current can reduce the AC input impact effect
With short-circuit and overload protection
Compact size, light weight
100% full-load burn-in test
Installed with EMI filter, minimum wave
2 years warranty
Safety:
1 EMC standard: Comply with EN55022,CLASSA
parameter:
|
Model
|
SMT-005-025SA
|
SMT-012- 025SA
|
SMT-024- 025SA
|
SMT-036- 025SA
|
SMT-048- 025SA
|
|
output
|
DC voltage
|
5V
|
12V
|
24V
|
36V
|
48V
|
|
Voltage tolerance
|
±2%
|
±1%
|
±1%
|
±1%
|
±1%
|
|
Rated current
|
5A
|
2.08A
|
1.04A
|
0.69A
|
10.52A
|
|
Current range
|
0~5A
|
0~2.08A
|
0~1.04A
|
0~0.69A
|
0~0.52A
|
|
Rated power
|
25W
|
25W
|
25W
|
25W
|
25W
|
|
Ripple&noise
|
100mvp-p
|
150mvp-p
|
150mvp-p
|
150mvp-p
|
150mvp-p
|
|
DCvoltage ADJ.range
|
± 10%
|
±10%
|
±10%
|
±10%
|
±10%
|
|
input
|
Voltage range
|
100~240Vdc
|
|
frequency
|
47~63HZ
|
|
AC current
|
3.2A/115VAC,1.6A/230VAC
|
|
efficiency
|
83%
|
83%
|
83%
|
83%
|
83%
|
|
Inrush current
|
Cold start current 18A/115VAC,36A/230VAC
|
|
Leakage current
|
< 1mA/240VAC
|
|
protection
|
overload
|
Rated output power115%~150% start over load protection
|
|
protection type:cutoff output,recovery after restart power
|
|
Over voltage
|
6.8~8.2V
|
15.6~17.8V
|
18.6~20.8V
|
30.6~33.2V
|
33.2~35.6V
|
|
protection type:hiccup mode,auto-recovery after fault condition is removed
|
|
-----
|
-----
|
|
-----
|
|
environment
|
Working temp,humidity
|
-10°C~+60°C,20%~90%RH
|
|
Storagetemp,humidity
|
-20°C~+85°C,10%~95%RH non-condensing
|
|
Withstand vibration
|
10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes
|
|
safety
|
Withstand voltage
|
I/P-O/P:2.0KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
|
|
Isolated resistance
|
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
|
