Deep Cycle LiFePO4 Battery Pack 24V300Ah For Solar Storage

•Long lifetimes - 6000 cycles @85% DOD (dependant on actual DOD, usage & temp.) and low self-discharge rate

•2-tier protection & high quality  engineered BMS with cell level monitoring



Product Name


Deep Cycle LiFePO4 Battery Pack 24V300Ah For Solar Storage


48v battery bank solar system


Highlights

•Long lifetimes - 6000 cycles @85% DOD (dependant on actual DOD, usage & temp.) and low self-discharge rate

•Easily scalable and stackable 2.5kWh modules - up to 200kWh in a single installation

•2-tier protection & high quality  engineered BMS with cell level monitoring

•Short circuit/Temperature/Balancing/Over Current/Over Voltage protection

•Simple rack-based installation system

•LCD display available


Deep Cycle LiFePO4 Battery Pack 24V300Ah For Solar Storage

Our 24v 300Ah solar battery pack is scalable energy storage from 2.5 to 200 kWh

lithium battery 24v300AhLifepo4 battery 24v300Ah


Specification for Deep Cycle LiFePO4 Battery Pack 24V300Ah For Solar Storage

MODEL

OSN-ESS-24300L

PERFORMANCE

Rated Capacity (5hr)

300 Ah

Nominal Voltage

25.6 V

Discharge Ending Voltage

16 V

Charging Limited Voltage

31.2 V

Max. Charging Current

200 A

Max. Continuous Discharging Current

200A

Parallel Connection

Optional (up to 16P). When paralleling Max. charging current = 20A

Containing Cell

3.2V 75AH

Design Life

More than 10 years

Cycle Life

6000 cycles @85% DOD (dependant on actual DOD, usage & temp.)

Discharge Rate

1C

Response Time

> 1ms

MECHANICAL SPECIFICATIONS

Dimensions (W*D*H)


                                    573*240*373mm



Weight

70.3 Kg

Enclosure

Steel enclosure with protection handles



OTHER

Operating Temperature

Charging: 0 to +45°C Discharging: -20 to +60°C

Storage Temperature

-20 to +60°C

Humidity

5% to 95% Relative Humidity (Non-condensing)

Warranty

5 years


Other Features

-Safe and scalable

OSN LFP battery modules are a practical and economical battery system based on Lithium-iron-phosphate technology (LFP or LiFePO4).

Available in standard 2.5kWh modules, the LFP battery modules can be easily scaled in multiples up to 200kWh in a single installation, making them suitable for a range of applications.

-Efficient

OSN's LFP battery modules feature a round-trip efficiency of 92%, low self discharge rate of 3+ years, and unlike traditional lead acid battery.


Application:

Home Solar Energy Storage
