Advantages
1. Longer life span than traditional lead acid batteries
2. Much lower resistance and consequently recharge at a faster rate
3. Lighter than lead acid batteries, usually weighing about 1/4 less
4. LifeP04 provides twice the battery capacity in the same amount of space
5. Handle far wider variations in temperature, with operating ranges from -40 to 158 degrees Fahrenheit
Technical Parameters
|
|
Type
|
lithium battery
|
Nominal voltage
|
48V
|
|
Rated capacity
|
200Ah (0.2C/25°C) (Min:148Ah)
|
Energy
|
9600Wh
|
|
Internal Resistance
|
≤100mΩ
|
Operating voltage range
|
42V- 58.4V (Typical:51.2V)
|
Charging voltage
|
56.0V±1.0V
|
Discharge cut-off voltage
|
42V±2.0V
|
Charging current
|
20A
|
Charging current(Max.)
|
30A
|
Discharge current(Max.)
|
100A(<3s)
|
Cycle Life
|
>2000 cycles @0.2C 100%DOD
|
Efficiency of Charge
|
100% @0.3C
|
Function
|
Parallel
|
Support (difference of Pack's voltage< 0.5V)
|
Terminal stud
|
4P
|
Alarm&potection
|
Over Voltage, Under Voltage, Over Current, Over temperature, Short Circuit etc.
|
Terminal stud
|
M8 crew nut
|
Mechanical Specifications
|
|
Size
|
1030*650*300mm
|
|
Weight
|
130kg
|
Packing
