1. Advantage
. Japanese Isuzu engine for selection;
. The eco-friendly design of the diesel forklift offers full protection to both the users and environment;
. Samll overall dimension, low centre of gravity, small turning radius, and the excellent manoeuvrability;
. The frame and the steeing axle of the material handing equipment are engineered with shock absorber to reduce . The impact and maximize the comfort during operation.
2. Features
Equipped with a mechanical synchronizer,
soft and smooth gear switching, avoid collision between gears to reduce noise,
increase gears working life
With aluminum radiator which has been
widely used on forklift, makes better cooling effect
High air intake system, effectively prevent
dust being absorbed, therefore extend working life of the engine.
Position of the seat and the angle of the
steering wheel are adjustable, improve operating room, makes comfort to drive
Our forklift has high-quality components and advanced features to keep your equipment up and running even in the harshest conditions. Our forklift factory is an industry leader in safety technology, with higher safety standards, reliable performance, and better machine performance.
Fashionable appearance, combined tail lamps
at the back of overhead guard, noticeable and obvious, provide safer working
condition and more suitable for night operations, exterior design obtained
national patent
3. Specification
|
Model
|
CPCD10
|
CPCD15
|
CPCD18
|
|
1
|
Feature
|
Power Type
|
|
Diesel
|
|
2
|
Load Capcity
|
kg
|
1000
|
1500
|
1800
|
|
3
|
Load center
|
mm
|
500
|
|
4
|
Lift height
|
mm
|
3000
|
|
5
|
Free lift height
|
mm
|
155
|
|
6
|
Forkk size
|
L*W*H
|
mm
|
920×100×40
|
|
7
|
Mast tilt
|
FR/RR
|
。
|
6/12
|
|
8
|
Min turning Radius
|
mm
|
1880
|
1955
|
1985
|
|
9
|
Min Right angle stacking aisle width
|
mm
|
3290
|
3365
|
3395
|
|
10
|
Min right angle aisle width
|
mm
|
2080
|
2155
|
2185
|
|
11
|
Min ground clearance
|
mm
|
110
|
|
12
|
Height of overhead guard
|
mm
|
2060
|
|
13
|
Overhang
|
mm
|
410
|
|
14
|
Performance
|
Max driving speed
|
Full load
|
km/h
|
14.5
|
|
15
|
Max Lifting speed
|
Full load
|
mm/s
|
550
|
|
16
|
Max drawbar pull
|
Full load
|
KN
|
12
|
14
|
19
|
|
17
|
Gradeabiity
|
%
|
20
|
|
18
|
Dimension
|
Overall length
|
Without forks
|
mm
|
2160
|
2234
|
2271
|
|
19
|
Over width
|
mm
|
1080
|
|
20
|
Height mast lifted(with backrest）
|
mm
|
3930
|
|
21
|
Height mast lowered
|
mm
|
2010
|
|
22
|
Chassis
|
Tyre
|
Front
|
|
6.50-10-10PR
|
|
23
|
Rear
|
|
5.00-8-10PR
|
|
24
|
Wheelbase
|
mm
|
1400
|
|
25
|
Tread
|
FR/RR
|
mm
|
891/920
|
|
26
|
Self weight
|
Without load
|
Kg
|
2430
|
2790
|
2890
|
|
27
|
Drive
|
Battery
|
Voltage / Capacity
|
V/Ah
|
12/80
|
|
28
|
Engine
|
Model
|
|
XC485BPG
|
|
29
|
Rated Power
|
kw/r.p.m
|
30/2600
|
|
30
|
Rated Torque
|
Nm/r.p.m
|
131/1820
|
|
31
|
Bore * sTROKE
|
mm
|
85×100
|
|
32
|
No.of Cylinder
|
|
4
|
|
33
|
Displacement
|
L
|
2.27
|
|
34
|
Fuel tank capacity
|
L
|
49
|
|
35
|
Transmission
|
|
1/1manual shift
|
|
36
|
Operating Pressure
|
Mpa
|
15.5
|
|
37
|
Supplement
|
Tire type (FR/RR)
|
|
Pneumatic
|
|
38
|
Numbers of wheels
|
pcs
|
2/2
|
|
39
|
lowering speed (full load)
|
mm/s
|
430
|
|
40
|
Lowering speed ( unload)
|
mm/s
|
530
|
|
41
|
Axle load distribution (full load) (FR/RR)
|
kg
|
2840/380
|
3640/520
|
4040/600
|
|
42
|
Axle load distribution (unload) (FR/RR)
|
kg
|
1220/1020
|
1170/1490
|
1140/1750
|
