Double Layer Two Feeding Rolls Stackable Bottom Sealing Bag Making Machine

Simple operation,

reasonable design,

accurate bag making,

stable running

Machine Characteristics

The machine adopts full computer control system. Servo motor as fixed - length control.
Arbitrary length. Color magic eye is tracking automatically, it is accurate and stable. Machine will automatically stop when missing printing mark.
The machine is widely used in various industrial flat packaging pockets.

Technical Parameters

Model	Unit	30 inch	35 inch	40 inch	50 inch
Max sealing & cutting width	MM	700*2	800*2	900*2	1200*2
Max sealing & cutting length	MM	1500	1500	1500	2500
Max sealing & cutting thickness	MM	0.01-0.06	0.01-0.2	0.01-0.2	0.01-0.2
Length error	MM	0.3	0.3	0.3	0.3
Output	PCS/MIN	20-130	50-130	20-130	20-100
Start AC Motor with brake	KW	1.5	2.2	2.2	2.2
DELTA servo motor	KW	1.5	1.5	2.0	2.5
Film feeding Frequency motor	W	550*2	550*2	550*2	550*2
Top & bottom heat sealing knife	MM	760*2	890*2	1050*2	1300*2
Electric heat	KW	1.8*2	1.8*2	2.0*2	3.0*2
Machine standby power	KW	5.5	5.6	7.2	9.3

Details Show
