GE DS200SHVMG1AED
EMAIL: sales2@amikon.cn
WEB:http://www.amikong.com/
Skype:live:ariatang111
Mb(Whatsapp):+86-18020776791
Wechat:18020776791
SPECIFICATION
-
Manufacturer: GE General Electric
-
Series: Mark V
-
Part Number: DS200SHVMG1AED
-
Product Type: SCR High Voltage M-Frame Interface Board
-
DESCRIPTION
General Electric’s DS200SHVMG1AED is a SCR high voltage M-frame interface board. This card was developed for the Mark V series of optional and replacement boards. As a member of that series, this interface board can easily be installed across a wide range of GE brand drives and exciters. After installing the card, a medium for interfacing the SCR bridge from the M-frame drive and the power supplies found in either the DCFB or SDCI board as well as the power connect card, or PCCA.
A number of voltage and conversion functions are provided by installing this board into a drive. Differential frequency outputs ranging from 0 to 500 kHz are produced by the card converting shunt signals ranging between -500 and 500 mV. All conversions of these signals are performed by DC positive and negative floating shunts in the voltage controlled oscillator (VCO) circuits. Once converted, the differential frequency outputs are sent to the DCFB/SDCI board or the PCCA card. AC line currents on the board are provided a 10:1 current transformer attenuation. There are 17 configurable jumpers on board, allowing users to select attenuation rates.
