Dual-Shaft Planetary Vacuum Mixer With Containers

Compact Dual-Shaft Planetary Vacuum Mixer with Two Containers (150 ml) - MSK-SFM-16

MSK-SFM-16 is a UL/CSA ready Compact Dual Shaft Mixer which can mix slurry much more uniform than the single shaft and remove gas bubble more efficiently. It has a built-in pump which can evacuate the mixing container to -0.08 Mpa with three segments programmable mixing speed from 0 - 600 rpm.  It is a high-quality tool for preparing battery electrode paste and various ceramic materials in the research lab.



Voltage Input	Single Phase 208~240VAC, 50/60hz AC power plug is not included. Please click here to order the plug)
Power	200W
Rotary Speed	0 - 600  RPM
Mixing Container	Two vacuum sealed containers are included. 150ml stainless steel. Dual helical ribbon mixing blades are built on the lid of the container. 50mL and 500 ml SS container is available at extra cost
Vacuum Pump &  Vacuum Level	Built-in single stage vacuum pump  Vacuum Level: -0.08~0.09 Mpa
Parameter Contol Panel	3.5" Color touch screen control allows easy setting of parameters such as mixing speed, mixing time, vacuum on/off  Mixing Time:  0 - 600 minute  Mixing Speed:  0 - 600 rpm and 3 variations in 1 setting possible   Note:  Max. mixing speed depends on slurry viscosity.  Max.10000 Mpa.s is allowed at 600 rpm.  Lower speed will be required for more sticky slurry
Dimensions	330mm x 320mm × 570mm (L x W x H)
Shipping Dimensions	18'' x 18'' x 24'' (L x W x H)
Net Weight	70 lbs
Warranty	One year limited with lifetime technical support
Application Notes	For best result, please consider ordering a filter to remove larger particle in slurry ( click picture below to order )
