Dubai 5000L Isuzu FVR FVZ FTR Chassis Water Fire Tender Vehicle

Chassis

FTR Mid-duty chassis for Fire-fighting application

Model

PT5140GXF

Driving Type

4x2    (Left hand drive)

Wheelbase

4500 mm

Overall Dimension

8430×2500×3660 mm

Tank capacity

5000L water    (Max 6200L water capacity)

Fire Pump

Rated low pressure:1.0MPa, Flow rate:40L/S. Rear-mounted，Water delivery time：≤35s

Fire Cannon

Rated pressure≤1.0MPa,Rated Flow rate:30L/s, Throw range≥50m, Rotation angle：360°,

Cab

Double cab with Four doors, 6 seats with safe belts.

Engine

Model:

4HK1-TCG40

Type:

Diesel, turbo charged inter-cooled, 4 cylinder

Max. Power:

139 KW (190HP)

Gearbox

MLD 6-shift, mechanical type, 6 forward and 1 reverse with

Tire

9.00-20

Color

Red    (Any color & logos up to wish)

Max Speed

90 km/h
