53L 250°C DZF-6050 (1)Vacuum Lab Oven With Optional Vacuum Pump And 30 Segment Programmable Temperature Controller
SPECIFICATIONS
1 The DZF-6050 (1) Vacuum Lab Oven Is mainly used For scientific research units, specialty universities, laboratories, industrial mining enterprises etc and production field for materials drying and heat treatment under the vacuum state.
2 The DZF-6050 Vacuum Lab Oven for lithium battery field mainly used for lithium battery materials, electrode and battery core vacuum drying.
3 Use DZF-6050 Vacuum Lab Oven for material heating drying under vacuum states has advantages :
3.1 Can reduce the drying temperature
3.2 Avoid some objects heating to oxidation
3.3 Avoid heating air to kill living cells
3.4 No dust damage
|
Model
|
DZF-6050 Vacuum Drying Oven TOB-DZF-6050 (1)
|
|
Source voltage
|
110VAC or 220VAC +/-10% selectable
|
|
Power
|
1400W
|
|
Warranty
|
One Year Limited Manufacture Warranty with Life Time Support
|
|
Temperature range
|
RT+10-250℃, 30 Segment programmable Temperature control
|
|
Temperature fluctuation
|
±0.5℃
|
|
Vacuum degree
|
-0.1MPa
|
|
Inner box size(L*W*H)
|
415*345*370mm
|
|
Dimension(L*W*H)
|
710*560*550mm
|
|
Package size
|
650*850*700mm
|
|
Temperature controller
|
1 High precision microcomputer temperature controller, accurate temperature control
2 Working temperature can be set and working time can be set for 0-9999min.
3 When time reach, sound alarm, and when any error, also alarm. function
|
|
Inner box material
|
304 stainless steel
|
|
Outside shell material
|
High quality cold-rolled steel plate electrostatic spray
|
|
Box door
|
Toughened hulletproof double glass door
|
|
Safety device
|
With over temperature protection, grounding etc
|
|
Shelf
|
2pcs
1 Solid stainless steel shelf, guarantee the oven temperature
2 Mesh stainless steel shelf can be also chosen
|
