Efficient Deep Cycle LiFePO4 Battery Cell with Zero Memory Effect
Equipped with exclusive patented technology, the battery is more stable and has a service life of 5-8 years. Support five-year warranty service and more models available:3.2V100Ah/150AH/135AH/200AH/230AH/280AH/320AH
Professional lithium battery manufacturer in China for more than 10 years,rich exporting experience,our models exported to more than 15 Countries in the world ,enjoy good reputation ! Our products inlcudes:forklift lithium battery,AGV battery, RV battery and golf carts li ion battery and so on,customized battery available
Quick Details
| Common Cell Specifications | 3.2V150AH | remarks | ||
| Item | Specification | 0.5C standard discharge | ||
| 1 | nomial capacity | 150ah | ||
| 2 | delivery capacity | ≥150ah | mean operation volt | |
| 3 | nominal volt | 3.2V | ||
| 4 | charge volt | 2.5-3.65V | ||
| 5 | standard charge current | 0.5C | 0.5C constant current,3.65V constant voltage charge to 3.65V,continue charging till current decline to ≤0.05C |
|
| 6 | standard discharge current | 0.5C | ||
| 7 | max discharge current | 1C | ||
| 8 | max pulse discharge current | 1.5C | 30S | |
| 9 | cell internal impedance | ≤0.5MΩ | 1kHz；2%SOC | |
| 10 | operation temperature and relative humidity | charge | 0-50℃ 60±25%R.H |
Charge at a very low temperature such as blew 0℃,will be get a lower capacity and reduce cycle life of the battery |
| discharge | “-20-55℃” 60±25%R.H |
|||
| 11 | storage temperature for long time | “-20-55℃” 60±25%R.H |
Do not storage exceed half year. Must |
