Emerson EPRO PR9268/203-000 Electrodynamic Velocity Sensor

The PR9268/203-000 is a mechanical velocity sensor, manufactured and designed by Emerson EPRO as part of the PR9268 Series used in the measure case vibration.Please Contact Us For Best Price!





EPRO PR9268/203-000 Electrodynamic Velocity Sensor



The PR9268/203-000 is a mechanical velocity sensor, used to measure mechanical vibrations in the frequency range 4 to 1000 Hz, with measuring amplitudes up to 3000 μm, and provide a voltage signal proportional to the vibration speed. It is for absolute vibration measurement of critical turbo machinery applications such as steam, gas and hydro turbines, compressors, pumps and fans to measure case vibration.



Features



· For measuring vertical vibration of machinery

· Electrodynamic principle of operation

· Simple installation

· High sensitivity

· Rugged construction

· High operating temperature (-20 to +100°C)

· Measuring frequency range 4-1000 Hz

· Safety class ATEX can be achieved by using safety barriers Ex.



PR9268/203-000

Dynamic Performance

Sensitivity 28.5 mV/mm/s (723.9 mV/in/s)
Frequency Range 4 to 1000Hz
Natural Frequency 4.5Hz ± 0.75Hz @ 20°C (68°F)
Transverse Sensitivity 0.13 (PR9268/20x-x00) @ 110Hz
Vibration Amplitude (Mechanical Limit) 3000μm (4000μm) peak-peak
Amplitude Linearity < 2%
Maximum Acceleration 10g (98.1 m/s2) peak-peak continuous
20g (196.2 m/s2) peak-peak intermittent
Maximum Transverse Acceleration 2g (19.62 m/s2)
Damping Factor ~0.56 @ 20°C (68°F)
~0.42 @ 100°C (212°F)
Resistance 1875Ω ±10%
Inductance ≤ 90 mH
Active Capacity < 1.2 nF





EPRO PR9268/203-000



PR9268/203-000



100% brand new and original,All the goods will be tested before shipment.



For the in stock items, we will send the order out within 5-7 days after receive the payment.



Global supplier of quality automation and control components.





Topteng offers a 12-month warranty from the date of delivery.

In the event of non-conforming product ( if damaged or incorrect product is received ),

Any nonconformity must be reported within 7 days of receipt of goods.



Questions? Call +86 18050017653  or Email sales4@nseauto.com




Product Tags PR9268/203-000          EPRO PR9268/203-000          Emerson PR9268/203-000          PR 9268/203-000          PR9268/303-000 Vibration Sensor          Electrodynamic Velocity Sensor
