Encapsulated Common Mode Choke Coils Filters with 250V AC Rated Voltage

Encapsulated common mode choke coils has excellent frequency characteristics and attenuation characteristics. Widely used in computers. Switches DVD/VCD color TV telephone DC-DC modules UPS uninterruptible power supply. Other electrical devices.



Hefei Mycoil Technology Co.,LTD supplied various electronic components, all products design meets the UL certification. Our encapsulated mode choke coils mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS).



Quick Details

Part Number: MCT Case Potting H12C Series Common Mode Choke



Brand name: MCT

Type: Choke Inductor



Custom made: Available

Testing frequency: 1KHz/0.25V



Logo: Can be customized

Operating temperature:-40°C~+105°C.



Shipping: Air, Ship, etc

Certification: ISO9001,ROHS,CE



MOQ: Any quantity

Lead time: 25 days after payment



OEM: Available



Part Information

Product Name: Encapsulated Common Mode Choke Coils Filters with 250V AC Rated Voltage

Applications: Low Frequency AC Reactor. PC USB interface cable. Solar Power System. LCD panels. Power Conditioning System. Wind Power System. Automatic Drive Machine. RFI Suppression Choke

Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray

Samples time: 7-10 days for customized parts, 3-5 days for standard parts.



Product Specification

 Bset quality encapsulated common mode chokes with RoHS Certification


Typical electrical parameter

MCT Part No.

Inductance(mH) min

DC Resistance(Ω)max

Rated Current(A)

MCTH12C102A08

10.0

0.37

0.8

MCTH12C680A12

6.8

0.25

1.2

MCTH12C330A10

3.3

0.15

1.0

MCTH12C220A12

2.2

0.10

1.2

MCTH12C150A15

1.5

0.08

1.5

MCTH12C100A18

1.0

0.06

1.8

MCTH12C080A20

0.82

0.045

2.0

MCTH12C050A25

0.5

0.03

2.5

Welcome customized encapsulated common mode choke inductors, we can design for you.
