The 3300 XL NSv Transducer System is primarily used in applications where counter bore, side-view, or rear-view restrictions limit the use of standard Bently Nevada 3300 and 3300 XL 5 and 8 mm Transducer Systems. It is especially ideal for small target applications, such as measuring radial vibration on shafts smaller than 51 mm (2 in) or axial position on flat targets smaller than 15 mm (0.6 in).
This system is commonly applied in fluid-filmed bearing machines where a small shaft or reduced side-view is present. Its primary applications include:
Radial vibration and radial position measurements
Axial (thrust) position measurements
Tachometer and zero speed measurements
FAQ
1.What is the maximum shaft size for measuring radial vibration with the 3300 XL NSv system?
The system is ideal for measuring radial vibration on shafts smaller than 51 mm (2 in).
2.Can I use the 3300 XL NSv system to upgrade from an existing 3300 RAM system?
Yes, the 3300 XL NSv system can be used to upgrade from the 3300 RAM system. You can continue using your existing probe, extension cable, and monitoring system with the 3300 XL NSv Proximitor Sensor.
3.What types of measurements can be taken with the 3300 XL NSv system?
The 3300 XL NSv system supports various measurements, including radial vibration, radial position, axial position (thrust), and tachometer/zero-speed measurements.
