If the inverter needs to send the motor speed to other equipment for counting or speed measurement in addition to the encoder speed feedback vector control 2, please use the Lanhai Huateng PG feedback frequency division output card EX-PG04.
Optional Expansion Card
|
category
|
name
|
model
|
Function Description
|
reference
|
|
Operation panel
|
Operation panel (shuttle ;type)
|
V6−DP01
|
Full range of models
|
P2−**
|
|
Operation panel (button type)
|
V6−DP02
|
Full range of models
|
P2−**
|
|
Text display
|
EX−MT01
|
Man-machine interface - text display
|
P2−**
|
|
touch screen
|
EX−MT02
|
Human-machine interface - touch screen
|
P2−**
|
|
Fake panel
|
V6−DP03
|
Customer option
|
P2−**
|
|
Pallet
|
V6−DP05
|
Operation panel mounting accessories
|
P2−**
|
|
Expansion Card
|
Power monitoring card
|
EX−PA01
|
Three-phase input power supply phase loss / instantaneous power failure monitoring
|
P2−**
|
|
Phase detection card
|
EX−PA02
|
Three-phase input power phase detection
|
P2−**
|
|
External power rectifier card
|
EX−RF01
|
Control power is provided by external power supply
|
P2−**
|
|
Programmable CAN bus expansion card
|
EX−CA05
|
;
|
P2−**
|
|
Profibus DP communication card
|
EX−CA06
|
;
|
P2−**
|
|
Keyboard extension cord
|
2 m keyboard extension cable
|
CB1−200
|
;
|
P2−**
|
|
3 m keyboard extension cable
|
CB1−300
|
;
|
P2−**
|
