Factory Cost of 90 Watt LED Fitting Set AL Die Casting Housing For Flood Lights

1.Die casting Flood Lights housing for 80-120W

2. IP65 - IP67 standard.


4. ADC12 pure aluminum alloy, fully led flood lights housing production.


5. We do lights fixtures with customized mold, powder coating service, etc.



The improvement of our die cast flood lights housing FL07
1. Concealed screw on surface.
2. Gear type heat sink.
3. Protruding stage to protect painted surface.

4. Perfect drainage system with gutter inside.

5. High power 80-120w.




Detailed data
Item No.   MSL-FL07 Glass material   Tempered clear glass
Type  Die Casting Aluminum Led Flood Lights Die Cast Lighting Housing Luminousness(Glass)   95%
Brand   Mansolo Lens material   PMMA
Lampshade material   Aluminum alloy Luminousness(Lens)   92%
Surface treatment   Powder coating Power scope  80-120 W or Custom
Standard color   Black, dark grey, light grey IP rate   IP67
Warranty(housing)   5 years Salt spray   3000 hours
Fixture Parts   Surface cover/Lamp coeur/Fixed plate for lens/Heat sink body/Waterproof power box/Stents Housing Net weight 5.2 KG
Production process
(housing)

  Die casting/Machining/CNC/

polishing/powder coating

Housing size  L38*W19.5*H15.5CM

Features for Die Casting Housing :

        1. The shell adopts the high quality of lams and lanterns aviation aluminum die-casting, surface after polishing, nano electrostatic spraying, introduced large lamp plate heat dissipation design, greatly improve the effect of light and heat dissipation problems, effectively ensure the service life of light source and power supply in the bad environment.

        2. The lamp body adopts toughened glass and silica gel seal to meet the IP67 standard, and the excellent waterproof, dust-proof and anti-corrosion design can be used in rainy or cold areas for a long time.


       3. Pure aluminum alloy die casting housing, using ADC12.



Application scope:

        Those products are widely used in highway, railway, subway, tunnel and other underground places, underground parking garage workshop, large warehouse, sports venues and construction site, also can be used in the urban landscape, billboard, building facade illumination etc.
