Factory Price YH Flexible Copper Conductor Welding Cable

Professional production of all kinds of wire and cable, including welding cable, if you need, please contact us




welding-cable-_02

Product Description



  •  Product standard:
    The production standard for anti-flaming and fire-resistant cables is GB/T19666-2005,GB/T5023-2008,JB/T8734-2012

  • Main of cables features
    1,Uo/U is 450/750V,300/500,
    2,Long-term allowable temperature of the cable:The allowable temperature of 105 Cable should not exceed 105℃, the allowable temperature of other models should not exceed 70℃.

  • Application:

          Applicable to the cables and wires of rated yolatage 450/750V and less than 450/750V AC for power

          plant, householdelectrical applance,insurment and telecommunication equipment.







Conductor
Nominal Section

 ( mm2)

Conductive Core Thickness of
Section Sheath (mm)
Average Outer
Diameter (mm2)
20oC Conductor
Resistance≤(Ω/km)
Reference
Weight(kg/km)
Number/Diameter
of Core(mm)
Min Max YH YHF
10 322/0.20 1.8 7.5 9.7 146 153.51 146 153.51
16 513/0.20 2 9.2 11.5 218.9 230.44 218.9 230.44
25 798/0.20 2 10.5 13 316.6 331.15 316.6 331.15
35 1121/0.20 2 11.5 14.5 426 439.87 426 439.87
50 1596/0.20 2.2 13.5 17 592.47 610.55 592.47 610.55
70 2214/0.20 2.4 15 19.5 790 817.52 790 817.52
95 2997/0.20 2.6 17 22 1066.17 1102.97 1066.17 1102.97
120 1702/0.30 2.8 19 24 1348.25 1392.55 1348.25 1392.55
150 2135/0.30 3 21 27 1678.5 1698.72 1648.5 1698.72
185 1443/0.40 3.2 22 29 1983.8 2020.74 1983.8 2020.74

welding-cable-_03_20190916162533_20190916162203welding-cable-_05





BVVB-flat-cable-_08


BVVB-flat-cable-_09BVVB-flat-cable-_10BVVB-flat-cable-_11BVVB-flat-cable-_12

Our customers are located all over the world including China, Singapore, Malaysia, Indonesia, Korea, India, USA and many countries in Europe as well as Africa and South America.
