Fast Cutting Speed PCB Depaneling Router Machine
PCB depaneling router is the process of removing numerous smaller, individual boards from a larger tab panel during manufacturing.
Most PCBs are routed, which leaves the individual circuits connected to the panel frame by narrow tabs. The tabs are broken or snapped to singulate the circuits.
PCB Depaneling Router Features:
1. Two-slide PCB cutting tables
2. Low stress
3. Sharp cutting edge
4. Manul loading /unloading
5. High speed cutting by 4 axes control(XY moving at the same time)
6. Easy teaching with image processing
;
PCB Depaneling Router Specification:
|
Router Machine
|
|
|
X/Y Cutting Speed
|
0 ~100mm/s
|
|
Repeatability precision
|
± 0.01mm
|
|
X/Y1/Y2/Z control mode
|
Industrial IPC and PC
|
|
X/Y1/Y2/Z driven mode
|
AC Servo Motor
|
|
Operation and data storage
|
PC
|
|
Cutting Precision
|
± 0.05mm
|
|
Spindle Speed
|
60000rpm(Germany KKAVO)
|
|
Power Supply
|
220V/110V
|
|
Air Pressure
|
4.5kg/cm 2
|
|
Power Rate
|
1.8KW
|
|
Vacuum Cleaner
|
|
|
Mode
|
Up or Bottom
|
|
Power Supply
|
380V
|
|
Up Cleaner Dimension
|
L650*W400*H1350mm
|
|
Bottom Cleaner Dimension
|
L665*W635*H1650mm
|
Spare Parts Available:
1. Spare spindle motor and driver
2. Routing bits
3. XYZ axis motor and driver
4. Customized fixtures
PCB Depaneling Router Application:
PCB Depaneling Router Packaging:
Our Certificate:
Laser depaneling is the most innovative and promising technology for
cutting and separating printed circuit boards from panels, and it
differs from classical separation methods, especially for its
flexibility and stress-free processing. Laser Depaneling Cutting Machine
is a good helper for working efficiently.
