Fast
PCB Quick Turn Prototype 4-layer Circuit Board Built On FR-4 With 2oz and
Immersion Gold
(Printed
circuits boards are custom-made products, the picture and parameters shown are
just for reference)
1.1
General description
It's standard 1.60 mm
thick, white silkscreen over green solder mask covers both sides. This is a
power board, each layer true 2oz applied and thicker gold 4 micro inches are
plated on the pads. The base material is used from ITEQ IT-158, entire board
supplying 1 up PCB. They're fabricated per IPC 6012 Class 2 using supplied
Gerber data. Each 25 panels are packed for shipment.
1.2
Features and benefits
1.
Middle Tg PCB Shows outstanding thermal resistance and suitable for lead-free
process;
2. Very
Low Moisture Absorption and better CAF resistance;
3.
Gold has good oxidation resistance and good heat dissipation;
4.
Gold has long storage time, it can be stored for more than 1 year in vacuum
bag;
5.
Competitive price and On-time service;
6. ISO9001,
ISO14001, ISO13485, UL certified manufacturing factory;
7. More
than 18+ years of PCB experience;
8. Customer
complaint rate: <1%
9. Door
to door shipment service;
1.3
PCB Specifications
|
PCB SIZE
|
78 x 65mm=1PCS
|
|
BOARD TYPE
|
Multilayer
PCB
|
|
Number
of Layers
|
4 layers
|
|
Surface
Mount Components
|
YES
|
|
Through
Hole Components
|
YES
|
|
LAYER STACKUP
|
copper
------- 70um(2oz)+plate TOP layer
|
|
Prepreg 7628 0.195mm
|
|
copper ------- 70um(2oz) MidLayer 1
|
|
FR-4 0.2mm
|
|
copper ------- 70um(1oz) MidLayer 2
|
|
Prepreg 7628 0.195mm
|
|
copper ------- 70um(2oz)+plate BOT layer
|
|
TECHNOLOGY
|
|
|
Minimum Trace and Space:
|
11.81
mil / 7.8 mil
|
|
Minimum
/ Maximum Holes:
|
0.5
mm / 3.5 mm
|
|
Number
of Different Holes:
|
7
|
|
Number
of Drill Holes:
|
125
|
|
Number
of Milled Slots:
|
NO
|
|
Number
of Internal Cutouts:
|
NO
|
|
Impedance
Control:
|
NO
|
|
Number
of Gold finger:
|
NO
|
|
BOARD
MATERIAL
|
|
|
Glass
Epoxy:
|
FR-4 Tg150℃,
er<5.4.IT-158, ITEQ Supplied
|
|
Final
foil external:
|
2
oz
|
|
Final
foil internal:
|
2
oz
|
|
Final
height of PCB:
|
1.6
mm ±0.16
|
|
PLATING AND COATING
|
|
|
Surface Finish
|
Immersion gold
(32.1% ) 0.1µm over 3µm nickel
|
|
Solder
Mask Apply To:
|
TOP and Bottom,
14 micron Minimum
|
|
Solder
Mask Color:
|
Green,
PSR-2000GT600D, Taiyo Supplied.
|
|
Solder
Mask Type:
|
LPSM
|
|
CONTOUR/CUTTING
|
Routing
|
|
MARKING
|
|
|
Side of
Component Legend
|
TOP
and Bottom.
|
|
Colour
of Component Legend
|
White, IJR-4000
MW300, Taiyo brand
|
|
Manufacturer
Name or Logo:
|
Marked on the
board in a conductor and leged FREE AREA
|
|
VIA
|
Plated
through hole(PTH), minimum size 0.5 mm.
|
|
FLAMIBILITY RATING
|
UL
94-V0 Approval MIN.
|
|
DIMENSION TOLERANCE
|
|
|
Outline
dimension:
|
0.0059"
|
|
Board
plating:
|
0.0029"
|
|
Drill
tolerance:
|
0.002"
|
|
TEST
|
100%
Electrical Test prior shipment
|
|
TYPE OF ARTWORK TO BE SUPPLIED
|
email
file, Gerber RS-274-X, PCBDOC etc
|
|
SERVICE AREA
|
Worldwide,
Globally.
|
1.4
Applications
Radar
Detector
Multiplexer
Embedded
System
Wireless
Alarm
5G
Booster
Peripheral
Device
Mobile
Modem
RF
Amplifiers
Balanced
Mixer
Relays
(automotive and industrial)
A PCB prototype is an early sample of a product whose sole purpose is to test design concepts to see if they work. While most prototypes are typically used to test basic user functionality, engineers need some functional PCB prototypes to check the full functionality of the design. As a leading PCB Prototypes manufacturer in China, we are very confident in the manufactured PCB prototypes.
1.5
Capability of Fast Delivery
|
Types
|
Normal Lead time (≦1㎡)
|
Fast Lead Time (≦1㎡)
|
|
2L
|
5
Days
|
1
Day
|
|
4L
|
5
Days
|
2
Days
|
|
6L
|
6
Days
|
3
Days
|
|
8L
|
7
Days
|
4
Days
|
|
10L
|
9
Days
|
6
Days
|
|
12L
|
10
Days
|
6
Days
|
|
14L
|
13
Days
|
7
Days
|
|
16L
|
14
Days
|
7
Days
|
|
18L
|
15
Days
|
9
Days
|
|
20L
|
16
Days
|
10
Days
|
|
22L
|
17
Days
|
11
Days
|
|
24L
|
18
Days
|
12
Days
|
|
26L
|
19
Days
|
13
Days
|
|
28L
|
20
Days
|
14
Days
|
|
30L
|
21
Days
|
15
Days
|
|
32L
|
22
Days
|
16
Days
|
|
>32 Layers
|
Pending
|
Pending
|
|
|
|
Note:
|
|
1.The lead time is for new order
|
|
2.Exclude Sunday, holidays
|
|
3.There's Order limitation every day.
|
|
4.Exclude shipping time
|
|
5.Exclude special technics, such as heavy copper, peelable
mask, blind/buried via etc.
|
|
6.Exclude communications for engineering questions.
|
PCB prototypes are early samples of products built with the sole
purpose of testing design ideas to see if they work. Although most
prototypes, in general, are made to test basic user functionality,
engineers require somewhat, if not entirely, functional PCB prototypes
to check the complete functionality of designs.
