The module has a 24V output circuit to power its three general purpose (24 Vdc) inputs (see Figure 166 on page 281). The inputs require a contact in the field and will stay operational even if the 24 Vdc of one of the Control Processors is switched off.
|
|
|
FC-PSU-UNI2450U V1.0 Data sheet
|
The input of proximity switch signals to the SDIL-1608 module needs to be converted to a level that is suitable for the SDIL-1608 module.
|
|
The power for the connected field devices is supplied by an on-board DC/DC converter common to all sixteen channels.
|
|
LEDs on the front of the module indicate the status of the channel, loop and module diagnostics.
|
|
