Finisar FTL414QB2C 56G InfiniBand FDR/SAS 3.0/40G Ethernet 60m QSFP+ AOC

Finisar’s FTL414QB2C QSFP+ transceiver modules are designed for use in Ethernet, SAS, and Infiniband links over multimode fiber. They are compliant with the QSFP+ MSA1,2 and the Ethernet3, SAS and InfiniBand4 architecture specifications. The optical transceiver is compliant per the RoHS Directive 2011/65/EU5. See Finisar Application Note AN-2038 for more details6.


  • Wavelength850nm
  • Distance100m
  • Data Rate56G
  • Temperature0℃~70℃
  • Warranty1 Year
  • ConnectorMPO

Finisar FTL414QB2C 56G InfiniBand FDR/SAS 3.0/40G Ethernet 60m QSFP+ AOC


Features

Four-channel full-duplex transceiver module

Hot Pluggable QSFP+ form factor

Maximum link length of 60m on OM3 Multimode Fiber (MMF) and 100m on OM4 MMF

Up to 14.0625 Gb/s per channel

Unretimed XLPPI electrical interface

Maximum power dissipation <1.5W

Reliable VCSEL array technology

Extended operating case temperature range: 0ºC to 70ºC

Single 1x12 MPO receptacle

RoHS-6 Compliant


Applications

Infiniband 4xFDR

Infiniband 4xFDR10

Infiniband 4xQDR

SAS 2.1/3.0

IEEE 40GBASE-SR4
