Finisar FTLX1475D3BNL 10G 10km 1310nm Extended Temperature Single Mode Datacom SFP+ Optical Transceiver

Form Factor:

SFP+

Finisar's Extended Temperature FTLX1475D3BNL 10Gb/s Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 10-Gigabit Ethernet links up to 10km over Single Mode fiber. They are compliant with SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-LR/LW and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472. The FTLX1475D3BNL is a "limiting module", i.e., it employs a limiting receiver. The optical transceiver is compliant pepr the RoHS Directive 2011/65/EU.

Warranty1 Year
ConditionNew
Temperature-5-85
Data Rate10.5 Gb/s
Distance10km
Wavelength1310nm
ConnectorLC

Facebook Twitter Pinterest LinkedIn 分享

Description

Product Description:

Distance:10 km
Data Rate (max):10.5 Gb/s
Protocol:10x Fibre Channel Compliant 10 Gigabit Ethernet Compliant Wireless CPRI Compliant
Low End Case Temperature (°C):-5
High End Case Temperature (°C):85
Diagnostics:Digital
Transmitter:DFB Laser
Receiver:PIN
Voltage Supply:3.3
Connector:LC
Wavelength:1310nm Band

Product Feature:

Hot-pluggable SFP+ footprint
Supports 9.95 to 10.5Gb/s bit rates
Power dissipation < 1W
RoHS-6 compliant (lead-free)
Single 3.3V power supply
Maximum link length of 10km
Uncooled 1310nm DFB laser
Limiting electrical interface receiver
Duplex LC connector
Built-in digital diagnostic functions
Extended temperature range: -5°C to 85°C
