Standards
ASTM D 3078, GB/T 15171
Features
u Compressed air as source of power, program controlled to generate vacuum.
u Wholly automatic, auto vacuum and keep for set time, auto stop and return.
u High speed, high precision.
u Can manually pause and stop.
Specifications
|
Vacuum degree
|
0~-90Kpa
|
|
Vacuum precision
|
±1% of displayed value
|
|
Vacuum keeping time
|
0.01s~99.99h
|
|
Gas source
|
compressed air, 0.7~0.8Mpa
|
|
Vacuum chamber size
|
Φ270mm × 270mm
|
|
Instrument size
|
300mm × 430mm × 500mm
|
|
Weight
|
20kg
|
|
Power
|
100W
|
|
Power supply
|
AC 220V 50Hz
|
Configuration
Main machine body, power cable, vacuum barrel
User provide: gas source
