Feeding unit
|
|
|
|
|
|
|
|
Lead edge feeder
|
|
Using servo motors eliminates gear box and the need for maintenance.
|
|
|
|
|
|
|
|
Large side jogger
|
|
A large U-shaped jogger surely aligns sheet side edges.
|
|
|
|
|
|
|
|
First sheet automatic setting device
|
|
A block of first sheets after lot switching is automatically fed to the feeder.
|
|
|
|
|
|
|
Printing unit
|
|
|
|
|
|
|
|
Chambered doctor blade system
|
|
Option
The doctor blades scrape off ink stuck to the ceramic rolls to produce uniform ink coverage regardless of machine speed and sheet size, minimizing uneven color and blur. Shinko's unique shape of the chambered doctor blade system ensures sharp and high-quality print images.
|
|
|
|
|
|
|
|
New ink pump and selector valve
|
|
Packing for ink selector valves and hoses are not necessary to be replaced.
|
|
|
|
|
|
|
Carrying unit
|
|
|
|
|
|
|
|
Center-suction carrying belt
|
|
A carrying belt sucks and carries sheets in the center of the carrying system.
|
|
|
|
|
|
|
Slotting uni
|
|
|
|
|
|
|
|
Prevention program against slotter rear edge flipping
|
|
Scratches by the flipped rear edge are eliminated.
|
|
|
|
|
|
|
|
Scratches by the flipped rear edge are eliminated
|
|
Glue joint length is steplessly adjustable.
|
|
|
|
|
|
|
|
Image detection device for printing, gluing and foreign matter contamination (both sides)
|
|
Foreign matter in the boxes can be detected.
|
|
|
|
|
|
|
Forming gluer
|
|
|
|
|
|
|
|
Resin forming bar
|
|
A Teflon coated bar facilitates folding sheets.
|
|
|
|
|
|
|
|
Tubing type glue pump
|
|
A tubing pump specifically designed for glue is durable and hoses can be easily changed.
|
|
|
|
|
|
|
|
Independent drive of lower edge (crease)
|
|
By independently moving the lower edge, the settings can be adjusted according to the characteristics of each sheet.
|
|
|
|
|
|
|
|
Gluer head carrying roller
|
|
|
|
|
|
|
|
|
|
No-crush wheel of gluer belt holding roller
|
|
By using no-crush wheels to adjust the gluer belt, sheets are carried with high stability.
|
|
|
|
|
|
|
|
Squaring plate heater
|
|
Blowing heated air from the squaring plate facilitates drying glue.
|
|
|
|
|
|
|
|
Lower forming belt
|
|
Flaps of sheets are firmly held to fold sheets more accurately.
|
|
|
|
|
|
|
|
Automatic centering of resin forming bar
|
|
The end of a Teflon coated bar is automatically positioned optimally.
|
