Model
|
1000W
|
2000W
|
3000W
|
|
Inverter Rated capacity(W)
|
1000W
|
2000W
|
3000W
|
|
Inverter Input
|
Rated Battery Voltage
|
12V
|
24V
|
24V
|
24V
|
24V
|
48V
|
|
Commercial Power range (VAC)
|
100/110/120/127/220/230/240 (+25%,-35%)
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
Solar Input
|
Input power(W)
|
240W
|
720W
|
720W
|
960W
|
1200W
|
2400W
|
|
Maximum power (WP)
|
480WP
|
1440WP
|
1440WP
|
1920WP
|
2400WP
|
4800WP
|
|
Solar Controller (Optional)
|
Control Type
|
PWM or MPPT (Optional)
|
|
Rated Voltage
|
12V
|
24V
|
24V
|
24V
|
24V
|
48V
|
|
Rated Current
|
20A
|
30A
|
30A
|
40A
|
50A
|
50A
|
|
Equilibrium charging
|
29V
|
58V
|
|
Float charging pressure
|
27.4V
|
54.8V
|
|
Under voltage protection
|
22.2V
|
44.4V
|
|
Inverter Input
|
Commercial Power range (VAC)
|
100/110/120/127/220/230/240 (+25%,-35%)
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
Inverter Output
|
Rated capacity
|
1000W
|
2000W
|
3000W
|
|
Waveform
|
Pure sine wave
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
AVR voltage range(VAC)
|
100/110/120/127/220/230/240±10%
(Auto-sensing )
|
|
Protection
|
Over Load Protection
|
30 seconds delay shutdown for 105~130% exceeded
|
|
Battery
|
Type
|
Sealed, maintenance-free lead acid
|
|
Battery protection
|
Automatic self-test, discharge protection, over-charge protection, smart management system.
|
|
Recharge current
|
30A(Maximum)
|
|
DC voltaget
|
24VDC
|
48V
|
|
battery input voltage range
|
DC:22V~30V
|
DC:44V
~60V
|
|
Working Environment
|
Working Temperature
|
0ºC ~ 40ºC (0m~1500m)
|
|
Noise
|
60dB
|
|
Store Temperature
|
0ºC ~ 40ºC
|
|
Humidity
|
<95%
|
|
Size(L*W*H)
|
470*210*350mm
|
470*260*500mm
|
|
Packing Size(L*W*H)
|
540*270*400mm
|
540*320*560mm
|
|
Net weight(kg)
|
15
|
15
|
21
|
33
|
33
|
34
|
|
Gross weight(kg)
|
19
|
19
|
25
|
37
|
37
|
38
|
|
Pure Sine Wave Solar Power Inverte With Controller Technical Specifications
|
|
Model
|
5000W
|
8000W
|
10000W
|
|
Inverter Rated capacity(W)
|
5000W
|
8000W
|
10000W
|
|
Inverter Input
|
Rated Battery Voltage
|
48V
|
96V
|
192V
|
96V
|
192V
|
|
Commercial Power range (VAC)
|
100/110/120/127/220/230/240 (+25%,-35%)
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
Solar Input
|
Input power(W)
|
2400W
|
4800W
|
19200W
|
4800W
|
19200W
|
|
Maximum power (WP)
|
4800WP
|
9600WP
|
38400WP
|
9600WP
|
38400WP
|
|
Solar Controller (Optional)
|
Control Type
|
PWM or MPPT (Optional)
|
|
Rated Voltage
|
48V
|
96V
|
192V
|
96V
|
192V
|
|
Rated Current
|
50A
|
50A
|
100A
|
50A
|
100A
|
|
Equilibrium charging
|
58V
|
116V
|
232V
|
116V
|
232V
|
|
Float charging pressure
|
54.8V
|
110V
|
220V
|
110V
|
220V
|
|
Under voltage protection
|
44.4V
|
88.8V
|
178V
|
88.8V
|
178V
|
|
Inverter Input
|
Commercial Power range (VAC)
|
100/110/120/127/220/230/240 (+25%,-35%)
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
Inverter Output
|
Rated capacity
|
5000W
|
8000W
|
10000W
|
|
Waveform
|
Pure sine wave
|
|
Frequency(Hz)
|
50±0.5/60±0.5
|
|
AVR voltage range(VAC)
|
No
|
|
Protection
|
Over Load Protection
|
30 seconds delay shutdown for 105~130% exceeded
|
|
Battery
|
Type
|
Sealed, maintenance-free lead acid
|
|
Battery protection
|
Automatic self-test, discharge protection, over-charge protection, smart management system.
|
|
Recharge current
|
30A(Maximum)
|
|
DC voltaget
|
48V
|
96V
|
192V
|
96V
|
192V
|
|
battery input voltage range
|
DC:44V~60V
|
DC:88V~120V
|
DC:176V~240V
|
DC:88V~120V
|
DC:176V
~240V
|
|
Working Environment
|
Working Temperature
|
0ºC ~ 40ºC (0m~1500m)
|
|
Noise
|
60dB
|
|
Store Temperature
|
0ºC ~ 40ºC
|
|
Humidity
|
<95%
|
|
Size(L*W*H)
|
470*260*500mm
|
550*260*710mm
|
|
Packing Size(L*W*H)
|
540*320*560mm
|
620*330*770mm
|
|
Net weight(kg)
|
42
|
72
|
72
|
82
|
82
|
|
Gross weight(kg)
|
46
|
77
|
77
|
87
|
87
|
|
Remarks
|
Specifications subject to change without prior notice
|
|
Our company accept customized special specifications products
|
