External hanging design, can be directly used standard fork installation, no need for welding and other additional modiication, wide version and with a solid shelf.
- When using a forklift truck, it can adjust the fork spacing quickly and accurately without leaving the driving position, so as to facilitate the adjustment of pallets of different sizes, thus improving the operation efficiency.
- Please obtain the actual load capacity of the forklift / attachment from the forklift manufacturer.
- Requires an additional oil circuit for the forklift.
- Other sizes available on request.
Specification
Load Centre: 500mm
|
Type
|
Class
|
Distance Range
|
Pocket Width
|
Width
|
SWL
|
Lost Load
|
HCG
|
Weight
|
Suit Forklift
|
|
F-TJQ2A20-1040
|
II
|
55-735mm
|
120mm
|
1150mm
|
2500kg
|
62mm
|
46mm
|
72kg
|
2-2.5t
|
F-TJQ3A30-1100
|
II
|
55-790mm
|
125mm
|
1210mm
|
3500kg
|
62mm
|
46mm
|
72kg
|
3-3.5t
|
F-TJQ3A40-1300
|
III
|
45-900mm
|
150mm
|
1412mm
|
4500kg
|
103mm
|
46mm
|
84kg
|
4-4.5t
|
